TL055VDXC01 5.5 inch TFT LCD Screen 1080*1920 FHD LCD panel
Product Details:
| Place of Origin: | China |
| Brand Name: | TIANMA |
| Model Number: | TL055VDXC01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TL055VDXC01 | Diagonal Size: | 5.5" |
|---|---|---|---|
| Resolution: | 1080(RGB)×1920, FHD 403PPI | Display Area: | 68.04(W)×120.96(H) Mm |
| Viewing Angle: | 80/80/80/80 (Typ.)(CR≥10) | Display Colors: | 16.7M 70%NTSC |
| Light Source: | WLED [7S2P], W/O Driver | Designed For: | Mobile Phone |
| Frame Rate: | 60Hz | Touch Panel: | PCAP, I²C |
| Highlight: | H429AL01 V0 TFT LCD Screen,4.3"TFT LCD Screen,MDDI MIPI TFT LCD Screen |
||
Product Description
TL055VDXC01 5.5 inch TFT LCD Screen 1080*1920 FHD LCD panel
Product details :
| Brand | TIANMA |
| Model P/N | TL055VDXC01 |
| Diagonal Size | 5.5" |
| Panel Type | LTPS TFT-LCD, LCM |
| Resolution | 1080(RGB)×1920, FHD 403PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 68.04(W)×120.96(H) mm |
| Bezel Opening | - |
| Outline Dim. | 70.44(H)×128.29(V) mm |
| Treatment | Hard coating (2H) |
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating Mode | SFT, Normally Black, Transmissive |
| Support Color | 16.7M 70%NTSC |
| Light Source | WLED [7S2P], W/O Driver |
| Weight | TBD |
| Designed For | Mobile Phone |
| Frame Rate | 60Hz |
| Touch Panel | PCAP, I²C |
| Interface Type | MIPI (4 data lanes), 35 pinsFPC |
| Power Supply | 1.8/2.8V (Typ.)(VIO/VCC) |
| Environment | Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -40 ~ 80 °C |
