Industrial AUO IPS TFT LCD display 15.6 Inch G156HAN05.0 With EDP 30 Pins Interface
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | G156HAN05.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | G156HAN05.0 | Resolution: | 1920(RGB)×1080, FHD, 141PPI |
|---|---|---|---|
| Display Size: | 344.16(W)×193.59(H) Mm | Viewing Angle: | 89/89/89/89 (Typ.)(CR≥10) |
| Designed For: | Industrial | Display Colors: | 16.2M 100% SRGB |
| High Light: | ndustrial IPS TFT LCD display,15.6 Inch IPS TFT LCD display,Symmetry IPS TFT LCD display |
||
Product Description
Industrial IPS AUO 15.6 inch TFT-LCD display G156HAN05.0 lcd screen
Product details :
| AUO LCD SCREEN G156HAN05.0 | |
| Panel Brand | AUO |
| Panel Model | G156HAN05.0 |
| Panel Size | 15.6" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD, 141PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 344.16(W)×193.59(H) mm |
| Outline Size | 351.84(W)×208.88(H) ×6.5(D) mm |
| Surface | Hard coating (3H) |
| Brightness | 500 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | AHVA, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Display Colors | 16.2M 100% sRGB |
| Lamp Type | WLED , 50K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 580g (Max.) |
| Signal Interface | eDP (2 Lanes) , eDP1.2 , 30 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -10 ~ 60 °C ; Storage Temp.: -20 ~ 70 °C |
| Industrial IPS AUO 15.6 inch TFT-LCD display G156HAN05.0 lcd screen with Interface eDP 30 pins | |
