M185XW01 VD AUO LCD Panel 1366X768 18.5 Inch LCD Display Module

M185XW01 VD AUO LCD Panel 1366X768 18.5 Inch LCD Display Module

Product Details:

Place of Origin: China
Brand Name: AUO
Model Number: M185XW01 VD

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Delivery Time: 7 Days
Payment Terms: T/T, Western Union
Supply Ability: 100000 Unit/Units per Month
Get Best Price Contact Now

Detail Information

Model Name: M185XW01 VD Resolution: 1366(RGB)×768, WXGA, 84PPI
Display Size: 409.8(W)×230.4(H) Mm Viewing Angle: 85/85/80/80 (Typ.)(CR≥10)
Designed For: Desktop Monitor Display Colors: 16.7M 68% NTSC
High Light:

M185XW01 VD AUO LCD panel

,

18.5 Inch AUO LCD panel

,

Antiglare lcd display module

Product Description

M185XW01 VD AUO 1366X768 18.5 inch Monitor lcd display module





Product details :

AUO LCD SCREEN M185XW01 VD
Panel Brand AUO
Panel Model M185XW01 VD
Panel Size 18.5"
Panel Type a-Si TFT-LCD , LCM
Resolution 1366(RGB)×768, WXGA, 84PPI
Pixel Format RGB Vertical Stripe
Display Area 409.8(W)×230.4(H) mm
Bezel Opening 413.4(W)×234.0(H) mm
Outline Size 430.4(W)×254.6(H) ×10.4(D) mm
Surface Antiglare, Hard coating (3H)
Brightness 250 cd/m² (Typ.)
Contrast Ratio 1000:1 (Typ.) (TM)
Viewing Angle 85/85/80/80 (Typ.)(CR≥10)
Display Mode TN, Normally White, Transmissive
Best View on 6 o'clock
Response Time 3.6/1.4 (Typ.)(Tr/Td)
Display Colors 16.7M 68% NTSC
Lamp Type 10S4P WLED , 30K hours , Without Driver
Frequency 60Hz
Designed For Desktop Monitor
Touch Screen Without
Panel Weight 1.29Kgs (Typ.)
Signal Interface LVDS (1 ch, 8-bit) , 30 pins Connector
Input Voltage 5.0V (Typ.)
Environment Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
M185XW01 VD AUO 1366X768 18.5 inch Monitor lcd display module
