Outdoor Interactive Kiosk AUO LCD SCREEN Wall Mount Weatherproof M170EG01 VA
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | M170EG01 VA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | M170EG01 VA | Resolution: | 1280(RGB)×1024, SXGA, 96PPI |
|---|---|---|---|
| Display Size: | 337.92(W)×270.336(H) Mm | Viewing Angle: | 70/70/70/60 (Typ.)(CR≥10) |
| Designed For: | Desktop Monitor | Display Colors: | 16.2M 72% NTSC |
| High Light: | Interactive Kiosk AUO LCD SCREEN,M170EG01 VA AUO LCD SCREEN,Weatherproof AUO LCD SCREEN |
||
Product Description
70 weatherproof outdoor drive-thru interactive kiosk wall mount ticket vending machine M170eg01 va
Product details :
| AUO LCD SCREEN M170EG01 VA | |
| Panel Brand | AUO |
| Panel Model | M170EG01 VA |
| Panel Size | 17.0" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1280(RGB)×1024, SXGA, 96PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 337.92(W)×270.336(H) mm |
| Bezel Opening | 341.6(W)×274.0(H) mm |
| Outline Size | 358.5(W)×296.5(H) ×17.5(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 300 cd/m² (Typ.) |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| View Direction | 12 o'clock |
| Viewing Angle | 70/70/70/60 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 6/2 (Typ.)(Tr/Td) |
| Display Colors | 16.2M 72% NTSC |
| Lamp Type | 4 pcs CCFL , 50K hours , Without Driver |
| Designed For | Desktop Monitor |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 2.25Kgs (Typ.) |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| 70 weatherproof outdoor drive-thru interactive kiosk wall mount ticket vending machine m170eg01 va lcd panel led backlight | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping:
we will test them strictly before shipping.
we will ship it in 1-3 working days after your paying.we only ship according to the shipping address,if you want to change shipping address,pls contact me in advance in time.as to the shipping time,it usually will be 7-30 days,which will be different for different countries.
FAQ:
Q: Do you accept sample orders of M170EG01 VA ?
A: Of course!sample order is welcome !
Q: How long will I receive my goods M170EG01 VA ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can I pay my order of M170EG01 VA via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90days warranty .
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
