Outdoor 10.1 Inch 1280*720 LCD Panel Screen Display C101EAN02.0
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | C101EAN02.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | C101EAN02.0 | Resolution: | 1280(RGB)×720 WXGA 145PPI |
|---|---|---|---|
| Display Size: | 223.68(Horizontal)×125.82(Vertical) Mm | Viewing Angle: | 80/80/80/80 (Typ.)(CR≥10) |
| Used For: | Outdoor High Brightness Automotive Display | Touch Screen: | Without |
| Physical Dimension: | 238.6(horizontal)×148(vertical) ×10.8(thick) Mm | Visual Size: | 226.78(Horizontal)×132.22(Vertical) Mm |
| High Light: | industrial tft display 1280*720,C101EAN02.0 industrial tft display,Outdoor 10.1 industrial tft display |
||
Product Description
C102EVN01.0 New Original 10.2 inch LCD Display Panel for Car GPS Navigation DVD Player for AUO
Product details :
| AUO LCD SCREEN C101EAN02.0 | |
| manufacturer | AUO |
| Model Name | C101EAN02.0 |
| Diagonal size | 10.1 inch |
| Screen type | a-Si TFT-LCD, LCD module |
| Resolution | 1280(RGB)×720 WXGA 145PPI |
| Pixel arrangement | RGB vertical bar |
| Display size | 223.68(Horizontal)×125.82(Vertical) mm |
| physical dimension | 238.6(horizontal)×148(vertical) ×10.8(thick) mm |
| Visual size | 226.78(Horizontal)×132.22(Vertical) mm |
| Surface treatment | Antiglare |
| Display brightness | 780 cd/m² (Typ.) |
| Contrast | 1000:1 (Typ.) (transmission) |
| Best angle | Symmetry |
| Optical mode | AHVA, normally black display, transmissive |
| Viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| responding | 20/20 (Max.)(Tr/Td) ms |
| Display Colors | 16.7M 98% sRGB |
| Backlight type | WLED [8S3P], 10K hours, no driver |
| Touch Screen | Without |
| Refresh rate | 60Hz |
| Weight | 400±40g |
| Application | Outdoor High Brightness Automotive Display |
| Interface Type | 40 pins MIPI (4 data lanes), FPC |
| Supply voltage | 3.3/3.3V (Typ.)(VDD/VDDA) |
| Application Environment | Work: -30 ~ 85 °C; Storage: -40 ~ 95 °C; Vibration resistance: 2.9G (28.4 m/s²) |
|
10.1 inch; C101EAN02.0 1280*720 LCD Panel Screen Display |
|
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
Feedback
1.We depend on our customer satisfaction to succeed. Therefore, your feedback is extremely important to us.
2.If you are satisfied with our items, please leave us active feedback.
3.Contact us before leaving any neagtive or neutral feedback. We will work with you to slove any problems.
FAQ
Q: Do you accept sample orders for C101EAN02.0 ?
A: Of course!sample order is welcome !
Q: How long will I receive my goods of C101EAN02.0 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment for C101EAN02.0 ?
A: We accept T/T , Paypal , western union .
Q: Can You declare my order of C101EAN02.0 at a very low value ?
A: Yes , we can . pls inform us before shipping .
