AUO C080EAT02.0 TFT LCD Display 8.0 Inch Lcd Module 184PPI
Product Details:
Place of Origin: | China |
Brand Name: | AUO |
Model Number: | C080EAT02.0 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | C080EAT02.0 | Screen Size: | 8.0 Inch |
---|---|---|---|
Resolution: | 1280(RGB)×720 [WXGA] 184PPI | Active Area(mm): | 176.64 × 98.36 (H×V) |
Outline(mm): | 339.6 × 118.45 (H×V×D) | Mass: | 275g |
Luminance: | 650 (Typ.)(cd/m²) | Contrast Ratio: | 800 : 1 (Min.) (TM) |
High Light: | AUO C080EAT02.0 TFT LCD Display,8.0 Inch Lcd Module,Matte Surface 184PPI TFT LCD Display |
Product Description
AUO C080EAT02.0 TFT LCD display 8.0 inch lcd module
Product details :
AUO LCD SCREEN C080EAT02.0 | |
manufacturer | AUO |
Model Name | C080EAT02.0 |
Diagonal size | 8.0 inch |
Screen type | a-Si TFT-LCD, screen assembly |
Resolution | 1280(RGB)×720 WXGA 184PPI |
Pixel arrangement | RGB Horizontal Stripe |
Display size | 176.64(Horizontal)×98.36(Vertical) mm |
physical dimension | 339.6(Horizontal)×118.45(Vertical) mm |
Surface treatment | Matte |
Display brightness | 650 cd/m² (Typ.) |
Contrast | 800:1 (Min.) (transmission) |
Best angle | Symmetry |
Viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
responding | 20 (Max.)(Tr+Td) ms |
Number of pixels | 16.7M 80% NTSC |
Backlight type | WLED [6S4P], 10K hours, no driver |
Mass | 275g |
Used for | Automotive Display |
Refresh rate | 60Hz |
Touch function | PCAP |
Interface Type | LVDS (2 ch, 8-bit) , 40 pins FPC |
Supply voltage | 3.3/13.5/18/-8V (Typ.)(VDD/AVDD/VGH/VGL) |
Application Environment | Working temperature: -30 ~ 85 °C; Storage temperature: -40 ~ 95 °C; Vibration resistance: 2.9G (28.4 m/s²) |
AUO C080EAT02.0 TFT LCD display 8.0 inch lcd module |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
About transportation:
- Please provide the consignee's full name and detailed delivery address.
- We only ship according to the delivery address in the order, if you want to change the delivery address, please contact me in advance.
- NOTE: Buyer is responsible for all additional customs fees, brokerage fees, duties and taxes imported into your country.
FAQ:
Q: How can I trace my order of C080EAT02.0 ?
A: we will give you tracking number then you can trace your order from website.
Q: How to make payment of C080EAT02.0 ?
A: We accept T/T , Paypal , western union .
Q: Can you give me a discount if I need a large quantity of C080EAT02.0 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can I pay my order of C080EAT02.0 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
