8.0 inch 1280(RGB)×720 TFT AUO C080EAN01.0 LCD Display

All Category

Floor Standing Digital Signage

8.0 inch 1280(RGB)×720 TFT AUO C080EAN01.0 LCD Display

Brand Name:	AUO
Model Number:	C080EAN01.0
MOQ:	10pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

C080EAN01.0

Screen Size:

8.0 Inch

Resolution:

1280(RGB)×720 [WXGA] 184PPI

Active Area(mm):

176.64(H)×99.36(V) Mm

Outline(mm):

186.5(H)×117.12(V) ×10(D) Mm

Bezel Area(mm):

179.55(H)×105.36(V) Mm

Luminance:

400 Cd/m² (Min.)

Contrast Ratio:

1000:1 (Typ.) (TM)

Supply Ability:

100000 Unit/Units per Month

Product Description

8.0 inch 1280(RGB)×720 TFT AUO C080EAN01.0 LCD Display

Product details :

AUO LCD SCREEN C080EAN01.0
manufacturer	AUO
Model Name	C080EAN01.0
Diagonal size	8.0 inches
Screen type	LCM, a-Si TFT-LCD
Resolution	1280(RGB)×720 [WXGA] 184PPI
Pixel arrangement	RGB Vertical Stripe
Display size	176.64 × 99.36 mm (H×V)
physical dimension	186.5 × 117.12 × 10 mm (H×V×D)
Visual size	179.55 × 105.36 mm (H×V)
Surface treatment	Matte
Display brightness	400 cd/m² (Typ.)
Contrast	1000: 1 (Typ.) [Transmission]
Best angle	Symmetry
Optical mode	AHVA, normally black display, transmissive
Viewing angle	80/80/80/80 (Typ.)(CR≥10)
responding	20/20 (Typ.)(Tr/Td) ms
Number of pixels	16.7M 72% NTSC
Backlight type	8S2P WLED, 10K hours, no driver
Weight	TBD
Designed For	Automotive Display
Refresh rate	60Hz
Touch function	Without
Interface Type	LVDS (1 ch, 8-bit), FPC, 40 pins
Supply voltage	3.3/3.3V (Typ.)(VDD/AVDD)
Application Environment	Storage temperature: -40 ~ 95 °C Working temperature: -30 ~ 85 °C; Vibration resistance: 2.9G (28.4 m/s²)
8.0 inch 1280(RGB)×720 TFT AUO C080EAN01.0 LCD Display

Friendly reminder:

- Installation guide is not included, we are not responsible for any damage caused by installing this accessory, please make sure you understand how to install it before ordering.
- Special skills and techniques required for proper installation. We recommend that you perform repairs with the help of a qualified technician.
- Please make sure you understand the disassembly procedure before purchasing. Customers are strongly advised to test the product before installation.

Why Choose Us :

According to customers' various requests,

we can match all accessories which inclusive of driver board,

touch-screen, LED backlight & LVDS cables. TFT LCD,

LCD panel, LCD display,LCD screen, LCD monitor,

LCD module from 2.2 inch to 88 inch.

Quality promised, 100% original,fast delivery,

also enjoy one year guarantee !

Shipping and Package :

8.0 inch 1280(RGB)×720 TFT AUO C080EAN01.0 LCD Display 0

1)All of our product will be testing before shipping . So you can be assured the quality of our products

2) All Panels are packed with new and firm carton, capable of long distance transportation.

3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT

4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.

FAQ:

Q: If I place order now,when will you ship the goods of C080EAN01.0 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Can You declare my order of C080EAN01.0 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: How to make payment of C080EAN01.0 ?

A: We accept T/T , Paypal , western union .

Q: How long is the warranty ?

A: We offer 90 days warranty .
