Original Car CD/DVD Navigation 6.1 inch LCD Display Screen C061VTN01.0 LCD Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | C061VTN01.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | C061VTN01.0 | Screen Size: | 6.1 Inch |
|---|---|---|---|
| Resolution: | 800(RGB)×480 [WVGA] 153PPI | Display Area: | 136.2(H)×72(V) Mm |
| Outline Dim.: | 149(H)×84.4(V) ×6.61(D) Mm | Bezel Area: | 138.45(H)×74.2(V) Mm |
| Luminance: | 560 Cd/m² (Typ.) | Contrast Ratio: | 700:1 (Typ.) (TM) |
Product Description
Original Car CD/DVD Navigation 6.1 inch LCD Display Screen C061VTN01.0 LCD Panel
Product details :
| AUO LCD SCREEN C061VTN01.0 | |
| Panel Brand | AUO |
| Panel Model | C061VTN01.0 |
| Panel Size | 6.1" |
| Panel Type | LCM, a-Si TFT-LCD |
| Resolution | 800(RGB)×480, WVGA, 153PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 136.2(W)×72(H) mm |
| Bezel Opening | 138.45(W)×74.2(H) mm |
| Outline Size | 149(W)×84.4(H)×6.61(D) mm |
| Surface | Matte, Hard coating (3H) |
| Brightness | 560 cd/m² (Typ.) |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| Viewing Angle | 65/65/50/60 (Typ.) (CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 12/18 (Typ.)(Tr/Td) ms |
| Display Colors | 262K , 65% NTSC |
| Lamp Type | 5S2P WLED , 10K hours, without driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 110±10g |
| Designed For | Automotive Display |
| Signal Interface | Parallel RGB (1 ch, 6-bit) , 50 pins , terminal |
| Input Voltage | 3.0/11/15/-8V (Typ.)(VDDIO/AVDD/VGH/VGL) |
| Environment | Working: -30 ~ 85 °C ; Storage: -40 ~ 95 °C |
| Original Car CD/DVD Navigation 6.1 inch LCD Display Screen C061VTN01.0 LCD Panel | |
Remind:
1.) We are not professional photographers, so the photos are not very delicate, all photos shown online are taken in kind, so please make sure your items are the same as our photos! Please double check the photo and make sure it is exactly what you need, if you are not sure, please contact us directly and send us your photo or device number. We are not responsible for bad quotes. Thank you for your understanding! ! ! thanks
If you do not accept A+ compatible touchscreen digitizers with different flex cable numbers, please do not buy as our title/description/photo condition is not available in the market, thank you!
2.) Please leave your accurate full name (especially buyers from Russia) and phone number when filling in the buyer information, so that the courier can deliver your item in time and easily.
3.) Do not install touch screen and LCD monitor on the machine before testing.
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ:
Q: If I place order now,when will you ship the goods of C061VTN01.0 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Do you accept sample orders of C061VTN01.0 ?
A: Of course!sample order is welcome !
Q: How to make payment of C061VTN01.0 ?
A: We accept T/T , Paypal , western union .
