7.0 inch lcd display 800*480 LCD Screen Display Panel JE070IA-18J
Product Details:
| Place of Origin: | China |
| Brand Name: | Innolux |
| Model Number: | JE070IA-18J |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | JE070IA-18J | Screen Size: | 7.0" |
|---|---|---|---|
| Resolution: | 800(RGB)×480, WVGA 133PPI | Active Area: | 152.4(W)×91.44(H) Mm |
| Outline Dim.: | 160.2(H)×101.7(V)×1.27(D) Mm | Treatment: | Hard Coating |
| Luminance: | 0 Cd/m² | Contrast Ratio: | 1000:1 (Typ.) (TM) |
| View Direction: | Symmetry | Designed For: | Automotive Display |
Product Description
7.0 inch lcd display 800*480 LCD Screen Display Panel JE070IA-18J
Product details :
| Brand | Innolux |
| Model P/N | JE070IA-18J |
| Diagonal Size | 7.0" |
| Panel Type | a-Si TFT-LCD, CELL, FOB |
| Resolution | 800(RGB)×480, WVGA 133PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 152.4(W)×91.44(H) mm |
| Bezel Opening | - |
| Outline Dim. | 160.2(H)×101.7(V)×1.27(D) mm |
| Treatment | Hard coating |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10) |
| Operating Mode | IPS, Normally Black, Transmissive |
| Plate Thickness | 0.50+0.50 mm |
| Transmittance | 4.5% (Typ.) |
| Support Color | 16.7M 68%NTSC |
| Light Source | No B/L |
| Weight | 46.0±2.0g |
| Designed For | Automotive Display |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | TTL (1 ch, 8-bit), 60 pinsFPC |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C |
