AUO 20.1 Inch 1680×1050 Laptop LCD Panel Screen B201SW01 V0
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | B201SW01 V0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | B201SW01 V0 (AUO10AB) | Screen Size: | 20.1 Inch |
|---|---|---|---|
| Resolution: | 1680(RGB)×1050 [WSXGA+] 98PPI | Display Area: | 433.44(H)×270.9(V) Mm |
| Outline(mm): | 453.5(H)×296.5(V) ×8.5(D) Mm | Bezel Area: | 437.2(H)×274.7(V) Mm |
| Luminance: | 300 Cd/m² (Typ.) | Contrast Ratio: | 1000:1 (Typ.) (TM) |
| High Light: | laptop lcd panel 1680×1050,AUO 20.1 Inch laptop screen panel,laptop lcd panel B201SW01 V0 |
||
Product Description
AUO 20.1 Inch 1680×1050 Laptop LCD Panel Screen B201SW01 V0
Product details :
| AUO LCD SCREEN B201SW01 V0 (AUO10AB) | |
| Panel Brand | AUO |
| Panel Model | B201SW01 V0 (AUO10AB) |
| Panel Size | 20.1" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1680(RGB)×1050 [WSXGA+] 98PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 433.44 × 270.9 mm (H×V) |
| Bezel Opening | 437.2 × 274.7 mm (H×V) |
| Outline Size | 453.5 × 296.5 × 8.5 mm (H×V×D) |
| Surface | Glare (Haze 0%), Hard coating (3H), Reflection 4.5% (Max.) |
| Brightness | 300 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (Transmission) |
| Viewing Angle | 80/80/80/75 (Typ.) (CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Best View on | 12 o'clock |
| Response Time | 3.8/1.2 (Typ.)(Tr/Td) ms |
| Display Colors | 16.7M , 72% NTSC |
| Lamp Type | 2 pcs CCFL , 10K hours, no driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Form Style | Wedge (PCBA Bent, T≥5.2mm) |
| Designed For | Laptop |
| Signal Interface | LVDS (2 ch, 8-bit) , terminal, 40 pins |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating temperature: 0 ~ 50 °C ; Storage temperature: -20 ~ 60 °C |
| AUO 20.1 Inch 1680×1050 Laptop LCD Panel Screen B201SW01 V0 | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
Transport information:
We will ship within 1-5 business days after payment.
We provide some goods delivered by Hong Kong/China Post for free. Please contact me if you need it urgently.
The standard shipping method is International Air Mail.
Days to receive in most regions (2-3 weeks).
If you have not received your item within 30 working days (5 weeks), please contact us to check (Brazil). Italy. 5-8 weeks)
FAQ:
Q: If I place order now,when will you ship the goods of B201SW01 V0 (AUO10AB) ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: How long will I receive my goods B201SW01 V0 (AUO10AB) ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: How to make payment of B201SW01 V0 (AUO10AB) ?
A: We accept T/T , Paypal , western union .
