AUO B156XTT01.0 Laptop touch LCD Assembly LED Screen For Lenovo S510P

Brand Name:	AUO
Model Number:	B156XTT01.0
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

B156XTT01.0 (AUO10EC)

Screen Size:

15.6 Inch

Resolution:

1366(RGB)×768 [WXGA] 100PPI

Display Area:

344.232(H)×193.536(V) Mm

Outline(mm):

364.9(H)×224.56(V) ×5.2(D) Mm

Touch Panel:

PCAP, Optical Bonding

Luminance:

200 Cd/m² (Typ.)

Contrast Ratio:

500:1 (Typ.) (TM)

Supply Ability:

100000 Unit/Units per Month

Product Description

AUO B156XTT01.0 Laptop touch LCD Assembly LED Screen For Lenovo S510P

Product details :

AUO LCD SCREEN B156XTT01.0 (AUO10EC)
Panel Brand	AUO
Panel Model	B156XTT01.0 (AUO10EC)
Panel Size	15.6"
Panel Type	a-Si TFT-LCD , LCM
Resolution	1366(RGB)×768 WXGA 100PPI
Pixel Format	RGB Vertical Stripe
Display Area	344.232 × 193.536 mm (H×V)
Outline Size	364.9 × 224.56× 5.2 mm (H×V×D)
Surface	Hard coating (7H)
Brightness	200 cd/m² (Typ.)
Contrast Ratio	500:1 (Typ.) (TM)
Viewing Angle	45/45/15/35 (Typ.) (CR≥10)
Display Mode	TN, Normally White, Transmissive
Best View on	6 o'clock
Response Time	8 (Typ.)(G to G) ms
Display Colors	262K , 45% NTSC
Lamp Type	WLED , 15K hours, with LED driver
Frequency	60Hz
Touch Screen	PCAP, Optical Bonding
Form Style	Flat (PCBA Flat, T3.4~4.0mm)
Designed For	Laptop
Signal Interface	40 pins LVDS (1 ch, 6-bit) , terminal
Input Voltage	3.3V (Typ.)
Environment	Storage temperature: -20 ~ 60 °C Operating temperature: 0 ~ 50 °C
AUO B156XTT01.0 Laptop touch LCD Assembly LED Screen For Lenovo S510P
