LCD Laptop Screen

B156HAK02.0 HW0A Touch Lcd 15.6 slim 40PIN 1920*1080 Notbook screen

All Category

Floor Standing Digital Signage

B156HAK02.0 HW0A Touch Lcd 15.6 slim 40PIN 1920*1080 Notbook screen

Brand Name:	AUO
Model Number:	B156HAK02.0 HW0A
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

B156HAK02.0 HW0A (AUO20ED)

Screen Size:

15.6 Inch

Pixel Number:

1920(RGB)×1080 (FHD) 141PPI

Active Area(mm):

344.16 × 193.59 (H×V)

Outline(mm):

350.56 × 223.6 × 3.2 (H×V×D)

Luminance:

250 Cd/m² (Typ.)

Contrast Ratio:

700 : 1 (Typ.) (TM)

Used For:

Laptop

Supply Ability:

100000 Unit/Units per Month

Product Description

B156HAK02.0 HW0A Touch Lcd 15.6 slim 40PIN 1920*1080 Notbook screen

Product details :

AUO LCD SCREEN B156HAK02.0 HW0A (AUO20ED)
manufacturer	AUO
Model Name	B156HAK02.0 HW0A (AUO20ED)
screen size	15.6 inch
Screen type	a-Si TFT-LCD, LCD module
Resolution	1920(RGB)×1080 (FHD) 141PPI
Arrangement	RGB Vertical Stripe
Display size	344.16 × 193.59 (H×V)
physical dimension	350.56(W)×223.6(H) ×3.2(D) mm
Surface treatment	Antiglare
Display brightness	250 cd/m² (Typ.)
Contrast	700:1 (Typ.) (TM)
Best perspective	Symmetry
Optical mode	AHVA, Normally Black, Transmissive
Viewing angle	85/85/85/85 (Typ.)(CR≥10)
responding	25 (Typ.)(Tr+Td) ms
Number of Color	262K , 45% NTSC
Backlight type	WLED , 15K hours , With LED Driver
Outline Shape	Slim (PCBA Flat, T≤3.2mm)
Apply to	Laptop
Refresh rate	60Hz
Touch function	On-Cell Touch
Interface Type	eDP (2 Lanes), eDP1.2, 40 pins, connector
Supply voltage	3.3V (Typ.)
Maximum	Storage temperature: -20 ~ 60 °C Working temperature: 0 ~ 50 °C
B156HAK02.0 HW0A Touch Lcd 15.6 slim 40PIN 1920*1080 Notbook screen

Why Choose Us :

According to customers' various requests,

we can match all accessories which inclusive of driver board,

touch-screen, LED backlight & LVDS cables. TFT LCD,

LCD panel, LCD display,LCD screen, LCD monitor,

LCD module from 2.2 inch to 88 inch.

Quality promised, 100% original,fast delivery,

also enjoy one year guarantee !

Shipping and Package :

B156HAK02.0 HW0A Touch Lcd 15.6 slim 40PIN 1920*1080 Notbook screen 0

1)All of our product will be testing before shipping . So you can be assured the quality of our products

2) All Panels are packed with new and firm carton, capable of long distance transportation.

3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT

4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.

Shipping:

China Post and Hongkong Post take 15-40 days to arrive.
DHL Express. FEDEX, TNT, EMS arrived quickly within 3-5 days.
Notes
Thank you for your order when you are dissatisfied with our products and services. Please get in touch with us. We can solve problems together!
Finally, I hope you have fun at my shop!

FAQ:

Q: Can You declare my order of B156HAK02.0 HW0A (AUO20ED) at a very low value ?

A: Yes , we can . pls inform us before shipping .

Q: How long is the warranty of B156HAK02.0 HW0A (AUO20ED) ?

A: 90days warranty .

Q: Can you give me a discount if I need a large quantity of B156HAK02.0 HW0A (AUO20ED) ?

A: Of course!If you make a large order, we will give you a discount.

Q: If I order B156HAK02.0 HW0A (AUO20ED) now,when will you ship the goods ?

A: The order will be shipped within 2-3 working days after received your payment.
