B070ATN01.0 7.0 inch panel 1024x600 tft lcd display lcd 7.0 inch
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | B070ATN01.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | B070ATN01.0 | Screen Size: | 7.0 Inch |
|---|---|---|---|
| Resolution: | 1024(RGB)×600 [WSVGA] 169PPI | Display Area: | 153.6(H)×90(V) Mm |
| Outline Size: | 167.25(H)×104.65(V) ×4.8(D) Mm | Bezel Opening: | 155.6(H)×92.0(V) Mm |
| Weight: | 100g (Max.) | Application: | Pad & Tablet / Industrial / Digital Photo Frame / Portable DVD Player |
Product Description
B070ATN01.0 7.0 inch panel 1024x600 tft lcd display lcd 7.0 inch
Product details :
| AUO LCD SCREEN B070ATN01.0 | |
| manufacturer | AUO |
| Model Name | B070ATN01.0 |
| screen size | 7.0" |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 1024(RGB)×600 [WSVGA] 169PPI |
| Pixel | RGB Vertical Stripe |
| Display size | 153.6 × 90 mm (H×V) |
| physical | 167.25 × 104.65 × 4.8 mm (H×V×D) |
| Visual size | 155.6 × 92.0 mm (H×V) |
| Surface | Glare (Haze 0%), Hard coating (3H), Reflection 4.3% (Typ.) |
| Brightness | 350 (Typ.) |
| Contrast | 700:1 (Typ.) (transmission) |
| Optical mode | TN, normally white display, transmissive |
| Viewing angle | 75/75/70/75 (Typ.)(CR≥10) |
| responding | 16 (Typ.)(Tr+Td) ms |
| Number of | 262K/16.2M, 50% NTSC |
| Backlight type | 4S6P WLED, 15K hours, no driver |
| Screen weight | 100g (Max.) |
| Apply to | Pad & Tablet / Industrial / Digital Photo Frame / Portable DVD Player |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | LVDS (1 ch, 6/8-bit), FPC, 39 pins |
| Supply voltage | 3.3V (Typ.) |
| Maximum | Storage temperature: -30 ~ 70 °C Working temperature: -20 ~ 60 °C |
| B070ATN01.0 7.0 inch panel 1024x600 tft lcd display lcd 7.0 inch | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
Shipping:
We ship worldwide
In order to ensure that customers can install and use our products normally
We will test this product before shipping
Most items will ship within 2-4 business days of receipt of payment.
Please provide your correct and detailed address and telephone number to
Make sure to deliver on time. We are not responsible for incorrect or non-delivery addresses.
If you need to change your address, please contact us before payment.
Our prices do not include any duties or other taxes;
If you have any questions, please feel free to contact me
FAQ:
Q: Can you give me a discount if I need a large quantity of B070ATN01.0?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of B070ATN01.0 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How long will I receive my goods B070ATN01.0 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can I pay my order of B070ATN01.0 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
