LM238WQ1-SLA1 23.8 inch 2560*1440 lcd display screen panel
Product Details:
| Place of Origin: | China |
| Brand Name: | LG Display |
| Model Number: | LM238WQ1-SLA1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LM238WQ1-SLA1 | Screen Size: | 23.8" |
|---|---|---|---|
| Pixel Format: | 2560(RGB)×1440, Quad-HD 123PPI | Active Area: | 525.7(W)×295.7(H) Mm |
| Outline Dim.: | 543 × 317.4× 11.7 (H×V×D) | Bezel Opening: | 530.2(W)×299.6(H) Mm |
| Color Depth: | 16.7M 100%sRGB | Used For: | Desktop Monitor |
| Good View At: | Symmetry | Work Mode: | IPS, Normally Black, Transmissive |
Product Description
LM238WQ1-SLA1 23.8 inch 2560*1440 lcd display screen panel
Product details :
| Brand | LG Display |
| Model P/N | LM238WQ1-SLA1 |
| Diagonal Size | 23.8" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 2560(RGB)×1440, Quad-HD 123PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 525.7(W)×295.7(H) mm |
| Bezel Opening | 530.2(W)×299.6(H) mm |
| Outline(mm) | 543 × 317.4× 11.7 (H×V×D) |
| Treatment | Antiglare (Haze 25%), Hard coating (3H) |
| Luminance | 300 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 14 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | IPS, Normally Black, Transmissive |
| Color Depth | 16.7M 100%sRGB |
| Backlight | 18S3PWLED, 30K hours, No Driver |
| Mass | 2.31Kgs (Typ.) |
| Used for | Desktop Monitor |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (4 ch, 10-bit), 92 pinsConnector |
| Voltage Supply | 10.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ:
Q: Can I pay my order of LM238WQ1-SLA1 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of LM238WQ1-SLA1 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of LM238WQ1-SLA1 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How long will I receive my goods LM238WQ1-SLA1 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
