4.3 inch LCD Touch Panel Display A043FL01 V2 480*272
Product Details:
Place of Origin: | China |
Brand Name: | AUO |
Model Number: | A043FL01 V2 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | A043FL01 V2 | Screen Size: | 4.3 Inch |
---|---|---|---|
Pixel Format: | 480(RGB)×272, WQVGA, 128PPI | Active Area: | 95.04(W)×53.856(H) Mm |
Outline Dim.: | 105.5(W)×67.2(H) Mm | Bezel Area: | 97.64(W)×56.456(H) Mm |
Weight: | 56.0g | Touch Screen: | 4-wire Resistive Touch |
Product Description
4.3 inch LCD Touch Panel Display A043FL01 V2 480*272
Product details :
AUO LCD SCREEN A043FL01 V2 | |
manufacturer | AUO |
Model Name | A043FL01 V2 |
screen size | 4.3 inch |
Screen type | LTPS TFT-LCD , LCM |
Resolution | 480(RGB)×272, WQVGA, 128PPI |
Pixel configuration | RGB Vertical Stripe |
Display size | 95.04(W)×53.856(H) mm |
physical dimension | 105.5(W)×67.2(H) mm |
Visual size | 97.64(W)×56.456(H) mm |
surface treatment | Hard coating (3H) |
Brightness | 400 cd/m² (Typ.) |
Contrast | 300:1 (Typ.) (TM) |
Best angle | 6 o'clock |
Optical mode | TN, Normally White, Transmissive |
Viewing angle | 60/60/40/55 (Typ.)(CR≥10) |
Responding time | 15/20 (Typ.)(Tr/Td) |
Number of color | 16.7M |
Backlight type | 7S1P WLED , 10K hours , Without Driver |
Panel weight | 56.0g |
Apply to | Portable Navigation / MP3 PMP |
Refresh rate | 60Hz |
Touch function | 4-wire Resistive Touch |
signal system | Parallel RGB (1 ch, 8-bit) + SPI , 50 pins FPC |
Supply voltage | 3.0/3.6V (VDD)(Min./Max.) |
Maximum rating | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
4.3 inch LCD Touch Panel Display A043FL01 V2 480*272 |
