new and original LCD panel 5.5 inch HSD055BHW3-D00 LCD Screen Display

Brand Name:	HannStar
Model Number:	HSD055BHW3-D00
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

HSD055BHW3-D00

Screen Size:

Pixel Format:

720(RGB)×1280, WXGA 268PPI

Active Area:

68.04(W)×120.96(H) Mm

Outline Dim.:

70.38(H)×128.06(V)×0.4(D) Mm

Treatment:

Without Polarizer

Support Color:

16.7M 70%NTSC

Designed For:

Mobile Phone

Supply Ability:

100000 Unit/Units per Month

Product Description

new and original LCD panel 5.5 inch HSD055BHW3-D00 LCD Screen Display

Product details :

Brand	HannStar
Model P/N	HSD055BHW3-D00
Diagonal Size	5.5"
Panel Type	a-Si TFT-LCD, CELL, Q-CUT (Full Cell)
Resolution	720(RGB)×1280, WXGA 268PPI
Pixel Format	RGB Vertical Stripe
Active Area	68.04(W)×120.96(H) mm
Bezel Opening	-
Outline Dim.	70.38(H)×128.06(V)×0.4(D) mm
Treatment	Without Polarizer
Luminance	0 cd/m²
Contrast Ratio	900:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	10/20 (Typ.)(Tr/Td)
Viewing Angle	80/80/80/80 (Typ.)(CR≥10)
Operating Mode	IPS Pro, Normally Black, Transmissive
Plate Thickness	0.20+0.20 mm
Transmittance	11.9% (Typ.)(without Polarizer)
Support Color	16.7M 70%NTSC
Light Source	No B/L
Weight	-
Designed For	Mobile Phone
Frame Rate	-
Touch Panel	Without
D-IC Detail	COG Suggest HX8394-A01, HX8394-D, NT35521, NT35521S, ILI9881, RM68200, OTM1283A, OTM1284A
Environment	Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
