NL8060BC21-02 LCD MODULES new 8.4 INCH 800*600 DISPLAY SCREEN
Product Details:
| Place of Origin: | China |
| Brand Name: | NEC |
| Model Number: | NL8060BC21-02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | NL8060BC21-02 | Screen Size: | 8.4 Inch |
|---|---|---|---|
| Pixel Format: | 800(RGB)×600, SVGA, 119PPI | Display Area: | 170.4(W)×127.8(H) Mm |
| Outline Size: | 200(W)×152(H) Mm | Bezel Area: | 174.0(W)×131.4(H) Mm |
| Brightness: | 400 Cd/m² (Typ.) | Weight: | 330/350g (Typ./Max.) |
Product Description
NL8060BC21-02 LCD MODULES new 8.4 INCH 800*600 DISPLAY SCREEN
Product details :
| NEC LCD SCREEN NL8060BC21-02 | |
| Manufacturer | NEC |
| Model Name | NL8060BC21-02 |
| Screen Size | 8.4 inch |
| Panel type | a-Si TFT-LCD, LCD module |
| Number of pixels | 800(RGB)×600, SVGA, 119PPI |
| Pixel layout | RGB vertical bar |
| Display area | 170.4(W)×127.8(H) mm |
| Viewable area | 174.0(W)×131.4(H) mm |
| physical dimension | 200(W)×152(H) mm |
| Surface treatment | Clear, Hard coating (3H) |
| Panel brightness | 400 cd/m² (Typ.) |
| Contrast | 600:1 (Typ.) (TM) |
| Viewing angle | 80/80/80/60 (Typ.)(CR≥10) |
| Operating mode | TN, normally white display, transmissive |
| Best perspective | 6 o'clock |
| Reaction time | 6/19 (Typ.)(Tr/Td) ms |
| Display color | 262K/16.7M, 40% NTSC |
| type of light source | 2 pcs CCFL, without driver |
| working frequency | 60Hz |
| Panel weight | 330/350g (Typ./Max.) |
| Signal interface | LVDS (1 ch, 6/8-bit), 20 pins, connector |
| Drive screen voltage | 3.3V (Typ.) |
| working environment | Work: -10 ~ 70 °C; Storage: -20 ~ 80 °C; Vibration resistance: 2.0G (19.6 m/s²) |
| NL8060BC21-02 LCD MODULES new 8.4 INCH 800*600 DISPLAY SCREEN | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
contact us:
1. We can ship via express way, such as EMS, DHL,FEDEX,some special line. if you need, pls contact us for details.
2. We can not be responsible for any wrong or undeliverable addresses. Pls check address after you put an order.
3. We are not responsible for any tax or customs caused in buyers' countries. Hope you can understand
We work hard to make sure EVERY CUSTOMER 100% SATISFIED and resolve any problem for you .
Please feel free to contact us if you have any question. Your questions will be answered within 24h.
FAQ:
Q: Can you give me a discount if I need a large quantity of NL8060BC21-02 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can You declare my order of NL8060BC21-02 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: If I place order now,when will you ship the goods of NL8060BC21-02 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How to make payment of NL8060BC21-02 ?
A: We accept T/T , Paypal , western union .
