Original 10.4 inch EL640.480-AA1 LCD Display Screen

Original 10.4 inch EL640.480-AA1 LCD Display Screen

Product Details:

Place of Origin: China
Brand Name: Lumineq
Model Number: EL640.480-AA1

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Delivery Time: 7 Days
Payment Terms: T/T, Western Union
Supply Ability: 100000 Unit/Units per Month
Get Best Price Contact Now

Detail Information

Model Name: EL640.480-AA1 Screen Size: 10.4 Inch
Pixel Format: 640(RG)×480 (VGA) 77PPI Display Area: 211.1 × 158.3 (H×V)
Outline Size: 263 × 205.3 × 21 (H×V×D) Luminance: 20 Cd/m² (Typ.)
Response Time: 10 : 1 (Typ.) (TM) Weight: 800g

Product Description

Original 10.4 inch EL640.480-AA1 LCD Display Screen



Product details :

Lumineq LCD SCREEN EL640.480-AA1
Manufacturer Lumineq
Model Name EL640.480-AA1
Screen Size 10.4 inches
Screen type EL, EL display
Resolution 640(RG)×480 VGA 77PPI
Pixel arrangement RG vertical strip
Display area 211.1(Horizontal)×158.3(Vertical) mm
physical dimension 263(H)×205(vertical) mm
Display brightness 20 cd/m² (Typ.)
Contrast 10:1 (Typ.) (transmission)
Recommended perspective Full view
Response time 1 (Max.) ms
Viewing angle 70/70/70/70 (Typ.)
Support color 8 colors
type of light source Self-luminous, 50K hours
weight 800g
Touch technology No touch
Interface Type 40 pins Parallel Data (4-bit), Connector
Voltage supply 5.0/12.0V (Typ.)(VCC1/VCC2)
Application Environment Working temperature: -25 ~ 65 °C; Storage temperature: -40 ~ 85 °C
Original 10.4 inch EL640.480-AA1 LCD Display Screen


Why Choose Us :


According to customers' various requests,

we can match all accessories which inclusive of driver board,

touch-screen, LED backlight & LVDS cables. TFT LCD,

LCD panel, LCD display,LCD screen, LCD monitor,

LCD module from 2.2 inch to 88 inch.

Quality promised, 100% original,fast delivery,

also enjoy one year guarantee !


Shipping and Package :


Original 10.4 inch EL640.480-AA1 LCD Display Screen 0

1)All of our product will be testing before shipping . So you can be assured the quality of our products


2) All Panels are packed with new and firm carton, capable of long distance transportation.




4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.




There are three levels of shipping service available our: expedited shipping, standard shipping and economy shipping.

We suggest you'd better consider bothdelivery speedandshipping costs to decide which shipping service level is suitable for you. We will select the best shipping scheme for you from the shipping service level chosen by you upon ordering. Also, please make sure your shipping address is correct anddeliverable. We are not responsible for the shipping losses caused by buyers' wrong or undeliverable addresses.

Item(s) you ordered will be shipped out within 72 hours (excluding holiday periods) after payment confirmation.



Q: Do you accept sample order of BOE EL640.480-AA1 ?

A: Of course, Welcome come to order our sample.


Q: When will my order 10.4 inch lcd panel EL640.480-AA1 ship?

A: The order are shipped within 1-2 working days after received the payment.


Q: What happen if the lcd panel EL640.480-AA1 I received can't work ?

A: 10.4 inch lcd screen EL640.480-AA1 was Strictly tested before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .


Q: Are you manufactory or trade company?

A: We are a Trade Company , We are LCD panel professional distributors ,We have own warehouse and inventory. Our goal is to provide our customers with the best products.
