LG Display 3840*1600 LM375QW1-SSA1 LCD Panel For Advertising
Product Details:
Place of Origin: | China |
Brand Name: | LG Display |
Model Number: | LM375QW1-SSA1 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | LM375QW1-SSA1 | Screen Size: | 37.5 Inch |
---|---|---|---|
Screen Type: | 3840(RGB)×1600 [UHD] 110PPI | Display Area: | 879.36(H)×366.4(V) Mm |
Outline Size: | 890(H)×378.8(V) Mm | Support Color: | 1.07B 99% SRGB |
Weight: | 5.26/5.52kGS (Typ./Max.) | Designed For: | Desktop Monitor |
Product Description
LG Display 3840*1600 LM375QW1-SSA1 LCD Panel For Advertising
Product details :
LG Display LCD SCREEN LM375QW1-SSA1 | |
Manufacturer | LG Display |
Model Name | LM375QW1-SSA1 |
Screen Size | 37.5 inch |
Types of | a-Si TFT-LCD, LCM |
Resolution | 3840(RGB)×1600 UHD 110PPI |
Pixel arrangement | RGB vertical bar |
Display area | 879.36(H)×366.4(V) mm |
physical dimension | 890(H)×378.8(V) mm |
Surface treatment | Matte, Hard coating (3H) |
Display brightness | 300 cd/m² (Typ.) |
Contrast | 1000:1 (Typ.) (transmission) |
Recommended perspective | Full view |
Response time | 14 (Typ.)(G to G) ms |
Viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
Display mode | IPS, normally black display, transmissive |
Support color | 1.07B, 99% sRGB |
type of light source | WLED, 30K hours, no driver |
weight | 5.26/5.52kGS (Typ./Max.) |
Frame rate | 60Hz |
Interface Type | 30 pins eDP (4 Lanes), connector |
Voltage supply | 10.0V (Typ.) |
Application Environment | Working temperature: 0 ~ 50 °C; Storage temperature: -20 ~ 60 °C |
LG Display 3840*1600 LM375QW1-SSA1 LCD Panel For Advertising |
1.Lm375qw1-ssa1 (alias: lm375qw1 (SS) (A1)).
2.According to the product specification version ver0.0 released by LG display on July 19, 2016, lm375qw1-ssa1 has a display resolution of 3840 (RGB) × 1600 (UHD), a aspect ratio of 24:10 (W: H), and pixels are arranged in RGB vertical bars.
3.Its display area size is 879.36 × 366.4 (w × h) mm, appearance size is 890 × 378.8 (w × h) mm, surface treatment is fog surface, hard coating (3H), product net weight is 5.26/5.52kgs (typ. / max.).
4.In terms of backlight, this product adopts WLED luminous side entry light source, with the service life of 30K hours, excluding backlight drive.
5.Lm375qw1-ssa1 adopts EDP (4 lanes) signal interface, with a total of 30 pins and terminal connection. The drive screen voltage is 10.0v (typ.). Its typical vertical refresh rate FV is 60Hz.
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ:
Q: Can I pay my order of LM375QW1-SSA1 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of LM375QW1-SSA1 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Do you accept sample orders of LM375QW1-SSA1 ?
A: Of course!sample order is welcome !
Q: How can I trace my order of LM375QW1-SSA1 ?
A: we will give you tracking number then you can trace your order from website.
