LM238WF2-SSK1 LM238WF2(SS)(K1) LCD Screen 23.8 inch FHD Display New
Product Details:
| Place of Origin: | China |
| Brand Name: | LG Display |
| Model Number: | LM238WF2-SSK1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LM238WF2-SSK1 | Screen Size: | 23.8 Inch |
|---|---|---|---|
| Screen Type: | 1920(RGB)×1080, FHD, 92PPI | Display Area: | 527.04(W)×296.46(H) Mm |
| Outline Size: | 535(W)×313(H) ×13.2(D) Mm | Application: | Desktop Monitor |
| Luminance: | 250 Cd/m² (Typ.) | Contrast Ratio: | 1000:1 (Typ.) (TM) |
Product Description
LM238WF2-SSK1 LM238WF2(SS)(K1) LCD Screen 23.8 inch FHD Display New
Product details :
| Manufacturer | LG Display |
| Model Name | LM238WF2-SSK1 |
| Screen Size | 23.8 inches |
| Panel type | a-Si TFT-LCD, LCM |
| Number of pixels | 1920(RGB)×1080, FHD, 92PPI |
| Pixel layout | RGB vertical bar |
| Display area | 527.04(W)×296.46(H) mm |
| physical dimension | 535(W)×313(H) ×13.2(D) mm |
| Surface treatment | Matte (Haze 25%), Hard coating (3H) |
| Panel brightness | 250 cd/m2 (Typ.) |
| Contrast:1000:1 (Typ.) (TM) | 1000:1 (Typ.) (TM) |
| Viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating mode | AH-IPS, normally black display, transmissive |
| Best perspective | Full view |
| Reaction time | 14 (Typ.)(G to G) ms |
| Display color | 16.7M, 69% NTSC |
| type of light source:15S4P WLED, 30K hours, without driver | type of light source:15S4P WLED, 30K hours, without driver |
| working frequency:60Hz | working frequency:60Hz |
| Panel weight:1.91/2.01Kgs (Typ./Max.) | Panel weight:1.91/2.01Kgs (Typ./Max.) |
| Signal interface | LVDS (2 ch, 8-bit), 30 pins, connector |
| Drive screen voltage | 5.0V (Typ.) |
| working environment | Working: 0 ~ 50 °C; Storage: -20 ~ 60 °C |
| Manufacturer | LG Display |
| LM238WF2-SSK1 LM238WF2(SS)(K1) LCD Screen 23.8 inch FHD Display New | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
Guarantee and Refund
1. All items are in good condition.
2. If the item is defective ( rarely happen ), please inform us within 3 days after you receive it and return it within warranty period ( 12 months )
3. Returned items should have original packaging and in good condition if possible. Please provide us the tracking number and the returning reason.
FAQ:
Q: If I place order now,when will you ship the goods of LM238WF2-SSK1 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can You declare my order of LM238WF2-SSK1 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of LM238WF2-SSK1 ?
A: We accept T/T , Paypal , western union .
Q: How long is the warranty ?
A: We offer 90 days warranty .
