LM195WX1-SLC1 19.5 lcd panel 1440*900 original new quality
Product Details:
Place of Origin: | China |
Brand Name: | LG Display |
Model Number: | LM195WX1-SLC1 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | LM195WX1-SLC1 | Screen Size: | 19.5 Inch |
---|---|---|---|
Screen Type: | 1440(RGB)×900 [WXGA+] 87PPI | Display Area: | 418.608 × 262.35 Mm (H×V) |
Outline Size: | 442.2 × 286.6 × 10.7 Mm (H×V×D) | Bezel Opening: | 422.2 × 265.9 Mm (H×V) |
Luminance: | 250 (Typ.) | Contrast Ratio: | 1000: 1 (Typ.) [Transmission] |
Product Description
LM195WX1-SLC1 19.5 lcd panel 1440*900 original new quality
Product details :
LG Display LM195WX1-SLC1 Mechanical Features
Screen Size : | 19.5" | |||
---|---|---|---|---|
Pixel Features : | Pixel Number | Pixel Format | Dot Pitch (H×V) | Pixel Pitch (H×V) |
1440(RGB)×900, WXGA+ | RGB Vertical Stripe | 0.0969×0.2907 mm | 0.2907×0.2907 mm [87PPI] | |
Mechanical Size : | Display Area (H×V) | Bezel Opening (H×V) | Overall Dimension (H×V) | Overall Depth |
418.608×262.35 mm | 422.2×265.9 mm | 442.2×286.6 mm | 8/10.7 (Typ./Max.) mm | |
Outline Features : | Form Shape | Aspect Ratio (H:V) | Orientation | Shape Style |
Flat Rectangle | 16:10 | Landscape type | Normal bezel | |
Other Spec : | Mass | Panel Cover | Surface Treatment | |
1.44Kgs (Typ.) | - | Antiglare, Hard coating (3H) | ||
Holes & Brackets : | Side mounting holes (4-M3) on left, right bezel |
Manufacturer | LG Display |
Model Name | LM195WX1-SLC1 |
Screen Size | 19.5" |
Screen type | LCM, a-Si TFT-LCD |
ResolutionI | 1440(RGB)×900 [WXGA+] 87PPI |
Pixel configuration | RGB vertical bar |
Display size | 418.608 × 262.35 mm (H×V) |
physical dimension | 442.2 × 286.6 × 10.7 mm (H×V×D) |
Visual size | 422.2 × 265.9 mm (H×V) |
Surface treatment | Matte, Hard coating (3H) |
Brightness (cd/m2) | 250 (Typ.) |
Contrast | 1000: 1 (Typ.) [Transmission] |
Best angle | Full view |
Optical mode | IPS, normally black display, transmissive |
Viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
responding speed | 14 (Typ.)(G to G) ms |
Number of colors | 16.7M, 72% NTSC |
Backlight type | 16S2P WLED, 30K hours, no driver |
Screen weight | 1.44Kgs (Typ.) |
Refresh ratez | 60Hz |
signal system | LVDS (2 ch, 8-bit), connector, 30 pins |
Supply voltage | 5.0V (Typ.) |
Maximum rating | Storage temperature: -20 ~ 60 °C Working temperature: 0 ~ 50 °C |
LM195WX1-SLC1 19.5 lcd panel 1440*900 original new quality |
