Kyocera New 5.7 inch TCG057VGLGA-G00 640x480 LCD Display Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | Kyocera |
| Model Number: | TCG057VGLGA-G00 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TCG057VGLGA-G00 | Screen Size: | 5.7 Inches |
|---|---|---|---|
| Pixel Number: | 640(RGB)×480 [VGA] 141PPI | Active Area(mm): | 115.2(H)×86.4(V) Mm |
| Outline(mm): | 134.5(H)×103.4(V) ×8.5(D) Mm | Visual Size: | 118.4(H)×89.6(V) Mm |
| Luminance: | 400 Cd/m² (Typ.) | Contrast Ratio: | 500:1 (Typ.) (TM) |
Product Description
Kyocera New 5.7 inch TCG057VGLGA-G00 640x480 LCD Display Panel
Product details :
| Kyocera LCD SCREEN TCG057VGLGA-G00 | |
| manufacturer | Kyocera |
| Model Name | TCG057VGLGA-G00 |
| screen size | 5.7 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 640(RGB)×480, VGA, 141PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 115.2(W)×86.4(H) mm |
| physical dimension | 134.5(W)×103.4(H) ×8.5(D) mm |
| Visual size | 118.4(W)×89.6(H) mm |
| surface treatment | Glare (Haze 0%) |
| Brightness | 400 cd/m² (Typ.) |
| Contrast | 500:1 (Typ.) (TM) |
| Optical mode | TN, Normally White, Transmissive |
| Viewing angle | 80/80/80/80 (Typ.)(CR≥5) |
| Responding time | 10/25 (Typ.)(Tr/Td) |
| Number of color | 16.7M 72% NTSC |
| Backlight type | WLED , 100K hours , Without Driver |
| Panel weight | 145g (Typ.) |
| Apply to | Industrial |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | Parallel RGB (1 ch, 6-bit) , 33 pins Connector |
| Supply voltage | 3.3V (Typ.) |
| Maximum rating | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| Kyocera New 5.7 inch TCG057VGLGA-G00 640x480 LCD Display Panel | |
