8 inch AUO Industrial LCD Screen Display Module G080UAN01.0 1200x1920
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | G080UAN01.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | G080UAN01.0 | Screen Size: | 8.0 Inch |
|---|---|---|---|
| Pixel Number: | 1200(RGB)×1920, WUXGA, 283PPI | Display Area: | 107.64(W)×172.224(H) Mm |
| Outline Size: | 114.6(W)×184.13(H) ×3.95(D) Mm | Panel Weight: | 80g (Max.) |
| Luminance: | 500cd/m² (Typ.) | Contrast Ratio: | 1000:1 (Typ.) (TM) |
| High Light: | 8 inch LCD Screen Display Module,1200x1920 industrial lcd display,G080UAN01.0 lcd display |
||
Product Description
New 8 inch For AUO 1200*1920 Industrial LCD Screen Display Module G080UAN01.0
Product details :
| AUO LCD SCREEN G080UAN01.0 | |
| manufacturer | AUO |
| Model Name | G080UAN01.0 |
| screen size | 8.0 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 1200(RGB)×1920, WUXGA, 283PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 107.64(W)×172.224(H) mm |
| physical dimension | 114.6(W)×184.13(H) ×3.95(D) mm |
| surface treatment | Glare (Haze 0%) |
| Brightness | 500cd/m² (Typ.) |
| Contrast | 1000:1 (Typ.) (TM) |
| Best angle | Full view |
| Optical mode | AHVA, Normally Black, Transmissive |
| Viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| Responding time | 27 (Typ.)(Tr+Tf) |
| Number of color | 16.7M 60% NTSC |
| Backlight type | 8S3P WLED , 20K hours , Without Driver |
| Panel weight | 80g (Max.) |
| Apply to | Industrial |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | MIPI (4 data lanes) , 45 pins Connector |
| Supply voltage | 3.3V (Typ.) |
| Maximum rating | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -20 ~ 70 °C |
| New 8 inch For AUO 1200*1920 Industrial LCD Screen Display Module G080UAN01.0 | |
After-sales service:
This product warranty for 6 months from the date of receipt of the customer, the human factor damage is not covered by the warranty the seller is not covered by the warranty shipping costs the refund will be return after the return parcel received.all goods are labeling identification do not tear, Otherwise will be no warranty, thank you for your understanding.
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Return Policy:
* All items can be returned within 7 days after receiving the package for refund (via PayPal), if the package is not opened. Buyer needs to be responsible for two-way shipping fee.
* All returned products must be in original condition, any used item will not be eligible for refund and exchange.
* The 20% re-stocking fee of original item cost will be applied for all non-defective, screen not used, screen not need, and wrong screen, order return or exchange.
* A Return Merchandise Authorization number (RMA) is required for all return. Without RMA number the return will not be accepted.
* We only accept the original package. Please make sure the item have no man-made damage.
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ:
Q: If I place order now,when will you ship the goods of G080UAN01.0 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: Can I pay my order of G080UAN01.0 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How can I trace my order of G080UAN01.0 ?
A: we will give you tracking number then you can trace your order from website.
Q: Do you accept sample orders of G080UAN01.0 ?
A: Of course!sample order is welcome !
