14.0 inch 1920*1080 TFT-lcd Display NV140FHM-T05
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | NV140FHM-T05 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | NV140FHM-T05 | Screen Size: | 14.0" |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080, FHD 157PPI | Active Area: | 309.31(W)×173.99(H) Mm |
| Outline(mm): | 314.31 × 183.79× 4.4 (H×V×D) | Treatment: | Hard Coating (3H) |
| Brightness: | 300 Cd/m² (Typ.) | Contrast: | 800 : 1 (Typ.) (TM) |
| Response: | 30 (Typ.)(Tr+Td) Ms | Used For: | Laptop |
Product Description
14.0 inch 1920*1080 TFT-lcd Display NV140FHM-T05
Product details :
| Brand | BOE |
| Model P/N | NV140FHM-T05 |
| Diagonal Size | 14.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080, FHD 157PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 309.31(W)×173.99(H) mm |
| Bezel Opening | - |
| Outline(mm) | 314.31 × 183.79× 4.4 (H×V×D) |
| Treatment | Hard coating (3H) |
| Luminance | 300 cd/m² (Typ.) |
| Contrast Ratio | 800 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 |
| Response | 30 (Typ.)(Tr+Td) ms |
| Good View at | - |
| Work Mode | ADS, Normally Black, Transmissive |
| Color Depth | 16.7M 100%sRGB |
| Backlight | 9S6PWLED, 15K hours, With LED Driver |
| Outline Shape | Slim (PCBA Bent, T≤3.0mm) |
| Used for | Laptop |
| Refresh Rate | 60Hz |
| Touchscreen | On-Cell Touch, I²C |
| Signal Type | eDP (2 Lanes), eDP1.2, HBR1 (2.7G/lane), 40 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ:
Q: How can I trace my order of NV140FHM-T05 ?
A: we will give you tracking number then you can trace your order from website.
Q: Can you give me a discount if I need a large quantity of NV140FHM-T05 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Do you accept sample orders of NV140FHM-T05 ?
A: Of course!sample order is welcome !
Q: Can I pay my order of NV140FHM-T05 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
