8.0 Inch 640*480 Interface Tft Lcd Display LQ080V3DG01
Product Details:
| Place of Origin: | China |
| Brand Name: | Sharp |
| Model Number: | LQ080V3DG01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LQ080V3DG01 | Screen Size: | 8.0 Inch |
|---|---|---|---|
| Pixel Number: | 640(RGB)×480 (VGA) 100PPI | Active Area: | 162.24 × 121.68 (H×V) |
| Physical Dimension: | 183 × 141 (H×V×D) | Mass: | 390±20g |
| Brightness: | 380 Cd/m² (Typ.) | Contrast: | 250 : 1 (Typ.) (TM) |
| High Light: | 100PPI 8.0 Inch Tft Lcd Display,LQ080V3DG01 Industrial LCD Panel,8.0 Inch 640x480 Tft Lcd Display |
||
Product Description
8.0 inch 640*480 Interface tft lcd display LQ080V3DG01
Product details :
| Sharp LCD SCREEN LQ080V3DG01 | |
| manufacturer | Sharp |
| Model Name | LQ080V3DG01 |
| screen size | 8.0 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 640(RGB)×480, VGA, 100PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 162.24(W)×121.68(H) mm |
| physical dimension | 183(W)×141(H) mm |
| surface treatment | Antiglare, Antireflection |
| Brightness | 380cd/m² (Typ.) |
| Contrast | 250:1 (Typ.) (TM) |
| Best angle | 6 o'clock |
| Optical mode | TN, Normally White, Transmissive |
| Viewing angle | 65/65/65/55 (Typ.)(CR≥10) |
| Responding time | 30/50 (Typ.)(Tr/Td) |
| Number of color | 262K |
| Backlight type | 1 pcs CCFL , 10K hours , Without Driver |
| Panel weight | 390±20g |
| Apply to | Industrial / Gaming |
| Touch function | No touch |
| signal system | Parallel RGB (1 ch, 6-bit) , 32 pins Connector |
| Supply voltage | 3.3/5.0V (Typ.)(VCC) |
| Maximum rating | Operating Temp.: 0 ~ 70 °C ; Storage Temp.: -25 ~ 70 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| 8.0 inch 640*480 Interface tft lcd display LQ080V3DG01 | |
