6.7 inch 1080*2400 TFT lcd panel CM6675JB2-1 LCD Display Screen
Product Details:
| Place of Origin: | China |
| Brand Name: | CSOT |
| Model Number: | CM6675JB2-1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | CM6675JB2-1 | Screen Size: | 6.7" |
|---|---|---|---|
| Pixel Number: | 1080(RGB)×2400 394PPI | Display Size: | 69.498(W)×154.44(H) Mm |
| Outline Size: | 71.098(H)×157.79(V)×0.51(D) Mm | Luminance: | 0 Cd/m² |
| Display Colors: | 16.7M 85%NTSC | Light Source: | No B/L |
| Designed For: | Mobile Phone | Touch Panel: | In-Cell Touch |
Product Description
6.7 inch 1080*2400 TFT lcd panel CM6675JB2-1 LCD Display Screen
Product details :
| Brand | CSOT |
| Model P/N | CM6675JB2-1 |
| Diagonal Size | 6.7" |
| Panel Type | LTPS TFT-LCD, CELL, Full Cell |
| Resolution | 1080(RGB)×2400 394PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 69.498(W)×154.44(H) mm |
| Bezel Opening | - |
| Outline Dim. | 71.098(H)×157.79(V)×0.51(D) mm |
| Treatment | - |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1500:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 25 (Max.)(Tr+Td) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Operating Mode | FFS, Normally Black, Transmissive |
| Plate Thickness | 0.16+0.16 mm |
| Transmittance | 4.65% (Typ.)(with Polarizer) |
| Support Color | 16.7M 85%NTSC |
| Light Source | No B/L |
| Weight | TBD |
| Designed For | Mobile Phone |
| Frame Rate | - |
| Touch Panel | In-Cell Touch |
| D-IC Detail | COG Suggest FT8756, HX83113A, NT36675, TC3318 |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ:
Q: How to make payment of CM6675JB2-1 ?
A: We accept T/T , Paypal , western union .
Q: Can you give me a discount if I need a large quantity of CM6675JB2-1 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Do you accept sample orders of CM6675JB2-1 ?
A: Of course!sample order is welcome !
Q: How long will I receive my goods CM6675JB2-1 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
