New LCD Panel CM6525LB2-1 720*1600 LCD display screen
  • name

New LCD Panel CM6525LB2-1 720*1600 LCD display screen

Brand Name: CSOT
Model Number: CM6525LB2-1
MOQ: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Payment Terms: T/T, Western Union
Detail Information
Product Description
Detail Information
Place of Origin:
China
Model Name:
CM6525LB2-1
Screen Size:
6.5"
Panel Type:
LTPS TFT-LCD, CELL, Full Cell
Display Area:
67.932(W)×150.96(H) Mm
Outline Size:
69.73(W)×155.11(H)×0.49(D) Mm
Treatment:
With Polarizer
Response Time:
25 (Typ.)(Tr+Td) Ms
Display Colors:
16.7M 69%NTSC
Used For:
Mobile Phone
Touchscreen:
In-Cell Touch
Supply Ability:
100000 Unit/Units per Month
Product Description

New LCD Panel CM6525LB2-1 720*1600 LCD display screen





Product details :



Brand CSOT
Model P/N CM6525LB2-1
Diagonal Size 6.5"
Panel Type LTPS TFT-LCD, CELL, Full Cell
Resolution 720(RGB)×1600 269PPI
Pixel Format RGB Vertical Stripe
Active Area 67.932(W)×150.96(H) mm
Bezel Opening -
Outline Size 69.73(W)×155.11(H)×0.49(D) mm
Treatment With Polarizer
Luminance 0 cd/m²
Contrast Ratio 1800 : 1 (Typ.) (TM)
Viewing Angle 80/80/80/80 (Typ.)(CR≥10)
Response 25 (Typ.)(Tr+Td) ms
Good View at Symmetry
Work Mode FFS, Normally Black, Transmissive
Glass Thickness 0.16+0.16 mm
Transmissivity 5.09% (Typ.)
Color Depth 16.7M 69%NTSC
Backlight No B/L
Mass -
Used for Mobile Phone
Refresh Rate -
Touchscreen In-Cell Touch
Driver IC list Suggest COG NT36575, FT8756, HX8311A, TC3318
Max. Ratings Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 60 °C

Why Choose Us :



According to customers' various requests,


we can match all accessories which inclusive of driver board,


touch-screen, LED backlight & LVDS cables. TFT LCD,


LCD panel, LCD display,LCD screen, LCD monitor,


LCD module from 2.2 inch to 88 inch.


Quality promised, 100% original,fast delivery,


also enjoy one year guarantee !



Shipping and Package :



New LCD Panel CM6525LB2-1 720*1600 LCD display screen 0

1)All of our product will be testing before shipping . So you can be assured the quality of our products



2) All Panels are packed with new and firm carton, capable of long distance transportation.



3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT



4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.



FAQ:

Q: How long is the warranty ?

A: We offer 90days warranty .



Q: If I place order now,when will you ship the goods of CM6525LB2-1 ?

A: The order will be shipped within 2-3 working days after received your payment.



Q: Can I pay my order of CM6525LB2-1 via credit card ?

A: Yes!you can use your credit card through your Paypal account.



Q: How long will I receive my goods CM6525LB2-1 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.



*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
