• AUO A018AN02 Ver.3 280×220 A-Si TFT LCD Panel 136PPI
AUO A018AN02 Ver.3 280×220 A-Si TFT LCD Panel 136PPI

AUO A018AN02 Ver.3 280×220 A-Si TFT LCD Panel 136PPI

Product Details:

Place of Origin: China
Brand Name: AUO
Model Number: A018AN02 Ver.3

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Delivery Time: 7 Days
Payment Terms: T/T, Western Union
Supply Ability: 100000 Unit/Units per Month
Get Best Price Contact Now

Detail Information

Model Name: A018AN02 Ver.3 Screen Size: 1.8 Inch
Resolution: 280×220, 136PPI Display Area: 35.6(W)×26.6(H) Mm
Outline Size: 48.68(W)×39.6(H) Mm Viewing Angle: 45/45/10/30 (Min.)(CR≥10)
Brightness: 150 Cd/m² (Typ.) Contrast Ratio: 150:1 (Typ.) (TM)
High Light:

150 cd/m2 TFT LCD Panel


RGB Delta TFT LCD Panel


136PPI 280×220 LCD Screen Display

Product Description

AUO A018AN02 Ver.3 280×220 a-Si TFT-LCD panel



Product details :

AU Optronics LCD SCREEN A018AN02 Ver.3
Panel Brand AU Optronics
Panel Model A018AN02 Ver.3
Panel Size 1.8"
Panel Type a-Si TFT-LCD , LCM
Resolution 280×220, 136PPI
Pixel Format RGB Delta
Display Area 35.6(W)×26.6(H) mm
Outline Size 48.68(W)×39.6(H) mm
Surface Hard coating (3H)
Brightness 150 cd/m² (Typ.)
Contrast Ratio 150:1 (Typ.) (TM)
Viewing Angle 45/45/10/30 (Min.)(CR≥10)
Display Mode TN, Normally White, Transmissive
Best View on Full view
Response Time 25/30 (Typ.)(Tr/Td)ms
Lamp Type WLED , 10K hours , Without Driver
Touch Screen Without
Panel Weight 20.0±5.0g
Signal Interface TFT Specific Analog RGB , 26 pins FPC
Input Voltage 5/5/15V (Typ.)(VCC/AVDD/VGH)
Environment Operating Temp.: 0 ~ 60 °C ; Storage Temp.: -20 ~ 80 °C
AUO A018AN02 Ver.3 280×220 a-Si TFT-LCD panel

AU Optronics A018AN02 Ver.3 Optical Features

Basic Information : Brightness Operating Mode Contrast Ratio
150 cd/m² (Typ.) TN, Normally White, Transmissive 150:1 (Typ.) (Transmissive)
Viewing Angle(L/R/U/D) Viewing Direction Response Speed
45/45/10/30 (Typ.)(CR≥10) 6 o'clock 25/30 (Typ.)(Tr/Td) (ms)
Dispaly Color : Color Temperature Color Amount White color Chromaticity
6963K Full color X:0.300; Y:0.350

Why Choose Us :


According to customers' various requests,

we can match all accessories which inclusive of driver board,

touch-screen, LED backlight & LVDS cables. TFT LCD,

LCD panel, LCD display,LCD screen, LCD monitor,

LCD module from 2.2 inch to 88 inch.

Quality promised, 100% original,fast delivery,

also enjoy one year guarantee !


Shipping and Package :


AUO A018AN02 Ver.3 280×220 A-Si TFT LCD Panel 136PPI 0

1)All of our product will be testing before shipping . So you can be assured the quality of our products


2) All Panels are packed with new and firm carton, capable of long distance transportation.




4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.



Q: How to make payment of A018AN02 Ver.3 ?

A: We accept T/T , Paypal , western union .


Q: Can you give me a discount if I need a large quantity of A018AN02 Ver.3 ?

A: Of course!If you make a large order, we will give you a discount.


Q: How can I trace my order of A018AN02 Ver.3 ?

A: we will give you tracking number then you can trace your order from website.


Q: How long is the warranty ?

A: We offer 90 days warranty .
