Name: 8.4 inch 640*480 Industrial LCD Panel Display LQ084V1DG43
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: LQ084V1DG43
Availability: InStock

Brand Name:	Sharp
Model Number:	LQ084V1DG43
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

LQ084V1DG43

Screen Size:

8.4 Inches

Pixel Number:

640(RGB)×480, VGA, 95PPI

Display Area:

170.88(W)×128.16(H) Mm

Outline Size:

221(W)×152.4(H)×9.8(D) Mm

Number Of Color:

262K

Luminance:

300cd/m² (Typ.)

Contrast Ratio:

600:1 (Typ.) (TM)

Supply Ability:

100000 Unit/Units per Month

Highlight:

LQ084V1DG43 Industrial LCD Display

8.4 inches 95PPI LCD Panel Display

LCD Panel Display 300cd/m2

Product Description

8.4 inch 640*480 Industrial LCD Panel Display LQ084V1DG43

Product details :

Sharp LCD SCREEN LQ084V1DG43
manufacturer	Sharp
Model Name	LQ084V1DG43
screen size	8.4 inch
Screen type	a-Si TFT-LCD, LCM
Resolution	640(RGB)×480, VGA, 95PPI
Pixel configuration	RGB vertical bars
Display size	170.88(W)×128.16(H) mm
physical dimension	221(W)×152.4(H)×9.8(D) mm
surface treatment	Matte, Hard coating (3H)
Brightness	300cd/m² (Typ.)
Contrast	600:1 (Typ.) (TM)
Best angle	12 o'clock
Optical mode	TN, Normally White, Transmissive
Viewing angle	70/70/60/50 (Typ.) (CR≥10)
Responding time	10/25 (Typ.)(Tr/Td)
Number of color	262K
Backlight type	WLED , 70K hours, with LED driver
Panel weight	340g (Max.)
Apply to	industry
Touch function	No touch
signal system	Parallel RGB (1 ch, 6-bit) , 31 pins , terminal
Supply voltage	3.3/5.0V (Typ.)(VCC)
Maximum rating	Working: -10 ~ 70 °C ; Storage: -25 ~ 70 °C
8.4 inch 640*480 Industrial LCD Panel Display LQ084V1DG43

Why Choose Us :

According to customers' various requests,

we can match all accessories which inclusive of driver board,

touch-screen, LED backlight & LVDS cables. TFT LCD,

LCD panel, LCD display,LCD screen, LCD monitor,

LCD module from 2.2 inch to 88 inch.

Quality promised, 100% original,fast delivery,

also enjoy one year guarantee !

Shipping and Package :

8.4 inch 640*480 Industrial LCD Panel Display LQ084V1DG43 0

1)All of our product will be testing before shipping . So you can be assured the quality of our products

2) All Panels are packed with new and firm carton, capable of long distance transportation.

3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT

4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.

FAQ:

Q: How can I trace my order of LQ084V1DG43 ?

A: we will give you tracking number then you can trace your order from website.

Q: Can you give me a discount if I need a large quantity of LQ084V1DG43 ?

A: Of course!If you make a large order, we will give you a discount.

Q: If I place order now,when will you ship the goods of LQ084V1DG43 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Can I pay my order of LQ084V1DG43 via credit card ?

A: Yes!you can use your credit card through your Paypal account.

*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
