7.0 inch tft lcd display 1280x800 TM070JDHG30
Product Details:
| Place of Origin: | China |
| Brand Name: | TIANMA |
| Model Number: | TM070JDHG30 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | TM070JDHG30 | Screen Size: | 7.0 Inches |
|---|---|---|---|
| Pixel Number: | 1280(RGB)×800, WXGA, 217PPI | Display Area: | 149.76(W)×93.6(H) Mm |
| Outline Size: | 161(W)×107(H) Mm | Bezel Opening: | 152.76(W)×96.6(H) Mm |
| Luminance: | 400 Cd/m² (Typ.) | Contrast Ratio: | 800:1 (Typ.) (TM) |
Product Description
7.0 inch tft lcd display 1280x800 TM070JDHG30
Product details :
| TIANMA LCD SCREEN TM070JDHG30 | |
| Panel Brand | TIANMA |
| Panel Model | TM070JDHG30 |
| Panel Size | 7.0" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1280(RGB)×800, WXGA, 217PPI |
| Pixel Format | RGB Vertical Stipe |
| Display Area | 149.76(W)×93.6(H) mm |
| Bezel Opening | 152.76(W)×96.6(H) mm |
| Outline Size | 161(W)×107(H) mm |
| Surface | Hard coating (3H) |
| Brightness | 400 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Display Mode | SFT, Normally Black, Transmissive |
| Best View on | 6 o'clock |
| Response Time | 2/10 (Typ.)(Tr/Td) |
| Display Colors | 16.7M 50% NTSC |
| Lamp Type | 3S7P WLED , 30K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 120g (Typ.) |
| Signal Interface | LVDS (1 ch, 8-bit) , 40 pins FPC |
| Input Voltage | 3.3/10.4/16/-6.8V (Typ.)(VDD/AVDD/VGH/VGL) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| 7.0 inch tft lcd display 1280x800 TM070JDHG30 | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ:
Q: How long will I receive my goods TM070JDHG30 ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can you give me a discount if I need a large quantity of TM070JDHG30 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can I pay my order of TM070JDHG30 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can You declare my order of TM070JDHG30 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
