Name: 10.4 Inch 1024x768 Industrial LCD Panel Display AA104XD12
Brand: Shenzhen Yongsheng Innovation Technology Co., Ltd
SKU: AA104XD12
Availability: InStock

Brand Name:	Mitsubishi
Model Number:	AA104XD12
MOQ:	1 pcs
Price:	Negotiable
Packaging Details:	Original packaging/conventional packaging box
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Model Name:

AA104XD12

Screen Size:

10.4 Inches

Pixel Number:

1024(RGB)×768, XGA, 123PPI

Display Area:

210.4×157.8(W×H) Mm

Outline Size:

230×180.2 ×11(W×H×D) Mm

Bezel Opening:

215.4×161.8(W×H) Mm

Luminance:

1000 Cd/m² (Typ.)

Contrast Ratio:

700:1 (Typ.) (transmission)

Supply Ability:

100000 Unit/Units per Month

Product Description

10.4 Inch 1024x768 Industrial LCD Panel Display AA104XD12

Product details :

Mitsubishi LCD SCREEN AA104XD12
Panel Brand	Mitsubishi
Panel Model	AA104XD12
Panel Size	10.4"
Panel Type	a-Si TFT-LCD , LCM
Resolution	1024(RGB)×768, XGA, 123PPI
Pixel Format	RGB Vertical Stripe
Display Area	210.4(W)×157.8(H) mm
Bezel Opening	215.4(W)×161.8(H) mm
Outline Size	230(W)×180.2(H) ×11(D) mm
Surface	Antiglare, Hard coating (3H)
Brightness	1000 cd/m² (Typ.)
Contrast Ratio	700:1 (Typ.) (TM)
Viewing Angle	80/80/65/65 (Typ.)(CR≥10)
Display Mode	TN, Normally White, Transmissive
Best View on	Symmetry
Response Time	4/12 (Typ.)(Tr/Tf)
Display Colors	262K/16.7M 40% NTSC
Lamp Type	4 strings WLED , 100K hours , Without Driver
Frequency	60Hz
Touch Screen	Without
Panel Weight	520g (Typ.)
Signal Interface	LVDS (1 ch, 6/8-bit) , 20 pins Connector
Input Voltage	3.3V (Typ.)
Environment	Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C
10.4 Inch 1024x768 Industrial LCD Panel Display AA104XD12

Why Choose Us :

According to customers' various requests,

we can match all accessories which inclusive of driver board,

touch-screen, LED backlight & LVDS cables. TFT LCD,

LCD panel, LCD display,LCD screen, LCD monitor,

LCD module from 2.2 inch to 88 inch.

Quality promised, 100% original,fast delivery,

also enjoy one year guarantee !

Shipping and Package :

10.4 Inch 1024x768 Industrial LCD Panel Display AA104XD12 0

1)All of our product will be testing before shipping . So you can be assured the quality of our products

2) All Panels are packed with new and firm carton, capable of long distance transportation.

3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT

4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.

FAQ:

Q: How long is the warranty ?

A: We offer 90days warranty .

Q: Can I pay my order of AA104XD12 via credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: If I place order now,when will you ship the goods of AA104XD12 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: How long will I receive my goods AA104XD12 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.

*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
