15.4 Inch LCD Display G154I1-LE1 Lcd Panel For Industry
Product Details:
| Place of Origin: | China |
| Brand Name: | Chimei Innolux |
| Model Number: | G154I1-LE1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | G154I1-LE1 | Screen Size: | 15.4 Inches |
|---|---|---|---|
| Pixel Number: | 1024(RGB)×768, XGA, 85PPI | Display Area: | 331.2(W)×207(H) Mm |
| Outline Size: | 352(W)×230(H) ×9.5(D) Mm | Bezel Opening: | 334.5(W)×210.3(H) Mm |
| Luminance: | 450 Cd/m² (Typ.) | Contrast Ratio: | 700:1 (Typ.) (transmission) |
| Highlight: | Industrial LCD Panel 15.4 Inch,G154I1-LE1 Lcd Panel For Industry |
||
Product Description
15.4 inch LCD display G154I1-LE1 lcd panel for industry
Product details :
| Chimei Innolux LCD SCREEN G154I1-LE1 | |
| Panel Brand | Chimei Innolux |
| Panel Model | G154I1-LE1 |
| Panel Size | 15.4" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1024(RGB)×768, XGA, 85PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 331.2(W)×207(H) mm |
| Bezel Opening | 334.5(W)×210.3(H) mm |
| Outline Size | 352(W)×230(H) ×9.5(D) mm |
| Surface | Antiglare, Hard coating (3H) |
| Brightness | 450 cd/m² (Typ.) |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| Viewing Angle | 80/80/70/70 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 5/11 (Typ.)(Tr/Td) |
| Display Colors | 262K/16.2M 56% NTSC |
| Lamp Type | 6 strings WLED , 50K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 880g (Typ.) |
| Signal Interface | LVDS (1 ch, 6/8-bit) , 30 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| 15.4 inch LCD display G154I1-LE1 lcd panel for industry | |
Chimei Innolux G154I1-LE1 Backlight Features
| Backlight Features: | Type | Position | Shape | Amount | Life(Hours) | Replacement |
|---|---|---|---|---|---|---|
| WLED | Edge light type | 6 strings | 6 strings | 50K(Min.) | Replaceable | |
| Interface Features : | Position | Type | WLED Driver | |||
| - | Included in signal interface | With LED Driver | ||||
| Driver Electrical : | Current Input | Voltage Input | Consumption | |||
| 850±100mA | 12.0±1.2V | 10.2±1.2W | ||||
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ:
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: How can I trace my order of G154I1-LE1 ?
A: we will give you tracking number then you can trace your order from website.
Q: Do you accept sample orders of G154I1-LE1 ?
A: Of course!sample order is welcome !
Q: Can I pay my order of G154I1-LE1 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
