55 Inch LCD Splicing Screen LCD Video Wall DV550FHM-NV6
Product Details:
| Place of Origin: | China |
| Brand Name: | BOE |
| Model Number: | DV550FHM-NV6 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | DV550FHM-NV6 | Screen Size: | 55 Inches |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080(FHD) 40PPI | Active Area(mm): | 1209.6 × 680.4 (H×V) Mm |
| Outline(mm): | 1211.3 × 682.1 × 57.1 (H×V×D) Mm | Patchwork: | 1.7 Mm (active To Active Seam) |
| Luminance: | 700 Cd/m² (Typ.) | Contrast Ratio: | 1200:1 (Typ.) (transmission) |
| High Light: | DV550FHM-NV6 DV550FHM-NV6,LCD Video Wall 700cd/m2 |
||
Product Description
55 inch LCD splicing screen LCD Video Wall DV550FHM-NV6
Product details :
| BOE LCD SCREEN DV550FHM-NV6 | |
| manufacturer | BOE |
| Model Name | DV550FHM-NV6 |
| screen size | 55.0 inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 1920(RGB)×1080(FHD) 40PPI |
| Pixel configuration | RGB vertical bars |
| Display size | 1209.6 × 680.4 (H×V) mm |
| physical dimension | 1211.3 × 682.1 × 57.1 (H×V×D) mm |
| surface treatment | Matte (Haze 25%), Hard coating (3H) |
| Brightness | 700cd/m² (Typ.) |
| Contrast | 1200:1 (Typ.) (TM) |
| Best angle | Full view |
| Optical mode | ADS, Normally Black, Transmissive |
| Viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| Responding time | 8 (Typ.)(G to G) ms |
| Number of color | 16.7M , 72% NTSC |
| Backlight type | WLED , with LED driver |
| Patchwork | 1.7 mm (active to active seam) |
| Apply to | multi-screen |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | LVDS (2 ch, 8-bit) , 51 pins |
| Supply voltage | 12.0V (Typ.) |
| Maximum rating | Storage temperature: -20 ~ 60 °C Operating temperature: 0 ~ 50 °C |
| 55 inch LCD splicing screen LCD Video Wall DV550FHM-NV6 | |
BOE DV550FHM-NV6 Optical Features
| Basic Information : | Luminance | Work Mode | Contrast Ratio |
|---|---|---|---|
| 700 cd/m² (Typ.) | ADS, Normally Black, Transmissive | 1200:1 (Typ.) (Transmissive) | |
| Good View at | Viewing Angle | Response Time | |
| Symmetry | 89/89/89/89 (Typ.)(CR≥10) | 8 (Typ.)(G to G) (ms) | |
| Dispaly Color : | Color Temperature: | Support Color | Color Coordinate |
| 9969K | 16.7M (8-bit) | X:0.280; Y:0.290 | |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 73% | 96% | 75% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 76% | 55% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| White Uniformity : | 1.18 (Typ.)(41 points) | ||
| Performance : | 3D Technology | Outdoor Visibility | Reflectance |
| - | Sunlight Readable | - | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ:
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can You declare my order of DV550FHM-NV6 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can I pay my order of DV550FHM-NV6 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How can I trace my order of DV550FHM-NV6 ?
A: we will give you tracking number then you can trace your order from website.
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
