LD550DUN-TKH1 1920×1080 Lcd Panel Display LCD Video Wall
Product Details:
| Place of Origin: | China |
| Brand Name: | LG Display |
| Model Number: | LD550DUN-TKH1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LD550DUN-TKH1 | Screen Size: | 55.0 Inches |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080[FHD] 40PPI | Active Area(mm): | 1209.6 × 680.4 Mm (H×V) |
| Outline(mm): | 1213.4 × 684.2 × 57.2 Mm (H×V×D) | Visual Size: | 1209.9 × 680.7 Mm (H×V) |
| Luminance: | 1500 Cd/m² (Typ.) | Contrast Ratio: | 1300:1 (Typ.) (transmission) |
| Highlight: | 55.0 inches 1920×1080 Lcd Panel Display,LD550DUN-TKH1 LCD Video Wall,40PPI 1920×1080 LCD Video Wall |
||
Product Description
LD550DUN-TKH1 1920×1080 lcd panel display LCD Video Wall
Product details :
| LG Display LCD SCREEN LD550DUN-TKH1 | |
| manufacturer | LG Display |
| Model Name | LD550DUN-TKH1 |
| screen size | 55.0 inch |
| Screen type | LCM, a-Si TFT-LCD |
| Resolution | 1920(RGB)×1080[FHD] 40PPI |
| Pixel configuration | RGB vertical bars |
| Display size | 1209.6 × 680.4 mm (H×V) |
| physical dimension | 1213.4 × 684.2 × 57.2 mm (H×V×D) |
| Visual size | 1209.9 × 680.7 mm (H×V) |
| surface treatment | Matte (Haze 3%), Hard coating (2H), Anti-Reflection Treatment |
| Brightness | 1500cd/m² (Typ.) |
| Contrast | 1300 : 1 (Typ.) [Transmission] |
| Best angle | Full view |
| Optical mode | S-IPS, Normally Black, Transmissive |
| Viewing angle | 89/89/89/89 (Min.)(CR≥10) |
| Responding time | 8 (Typ.)(G to G) ms |
| Number of color | 1.06B , 72% NTSC |
| Backlight type | WLED , 60K hours, with LED driver |
| Patchwork | 3.8 mm (active to active seam) |
| Apply to | multi-screen |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | LVDS (2 ch, 10-bit) , terminal, 51 pins |
| Supply voltage | 12.0V (Typ.) |
| Maximum rating | Storage temperature: -20 ~ 60 °C Operating temperature: 0 ~ 50 °C |
| LD550DUN-TKH1 1920×1080 lcd panel display | |
LG Display LD550DUN-TKH1 Backlight Details
| Back-light Features: | Lamp Shape | - | Lamp Type | WLED | Life Time | 60K(Typ.) (Hours) |
|---|---|---|---|---|---|---|
| Replacement | - | Amount | - | Position | Direct light type | |
| Interface Features : | Type | Connector | Position | - | Lamp Driver | With LED Driver |
| Interface Detail : | Brand | Model | Pin Pitch | Pins | Amount | Configuration |
| YEONHO | 20022WR-14B2 | 2.0 mm | 14 pins | 1 pcs | ||
| YEONHO | 20022WR-12B2 | 2.0 mm | 12 pins | 1 pcs | ||
| Driver Electrical : | Voltage Input | 24.0±2.4V | Current Input | 9.46/11.1A (Typ./Max.) | ||
| Consumption | 227.1/237.9W (Typ./Max.) | |||||
BOE DV550FHM-NV2 Backlight Features
| Backlight Features: | Type | Position | Shape | Amount | Life(Hours) | Replacement |
|---|---|---|---|---|---|---|
| WLED | Direct light type | - | - | - | - | |
| Interface Features : | Position | Type | WLED Driver | |||
| - | Connector | With LED Driver | ||||
| Interface Detail | Brand | Model | Amount | Pin Pitch | Pins | Pin Assignment |
| CviLux | CI0114M1HR0-NH | 2 pcs | 2.0 mm | 14 pins | ||
| Driver Electrical : | Current Input | Voltage Input | Consumption | |||
| 7.91/10.0A (Typ./Max.) | 24.0±2.4V | 190/205W (Typ./Max.) | ||||
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ:
Q: How long is the warranty ?
A: We offer 90days warranty .
Q: Can You declare my order of LD550DUN-TKH1 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: How to make payment of LD550DUN-TKH1 ?
A: We accept T/T , Paypal , western union .
Q: Can you give me a discount if I need a large quantity of LD550DUN-TKH1 ?
A: Of course!If you make a large order, we will give you a discount.
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
