49 inch LCD Panel for LG Display LD490DUN-TJA1 LCD Video Wall
Product Details:
| Place of Origin: | China |
| Brand Name: | LG Display |
| Model Number: | LD490DUN-TJA1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | LD490DUN-TJA1 | Screen Size: | 49.0 Inches |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080 FHD 45PPI | Active Area(mm): | 1073.78(Horizontal)×604(Vertical) Mm |
| Outline(mm): | 1075.58 (horizontal) × 605.8 (vertical) × 54.3 (thick) Mm | Responding Time: | 8 (Typ.)(G To G) Ms |
| Luminance: | 700 Cd/m² (Typ.) | Contrast Ratio: | 1300:1 (Typ.) (transmission) |
Product Description
49 inch LCD Panel for LG Display LD490DUN-TJA1 LCD Video Wall
Product details :
| LG Display LCD SCREEN LD490DUN-TJA1 | |
| manufacturer | LG Display |
| Model Name | LD490DUN-TJA1 |
| screen size | 49 inch |
| Screen type | a-Si TFT-LCD, LCD module |
| Resolution | 1920(RGB)×1080 FHD 45PPI |
| Pixel configuration | RGB vertical bar |
| Display size | 1073.78(Horizontal)×604(Vertical) mm |
| physical dimension | 1075.58 (horizontal) × 605.8 (vertical) × 54.3 (thick) mm |
| surface treatment | Matte (Haze 10%), Hard coating (2H) |
| Brightness | 700 cd/m² (Typ.) |
| Contrast | 1300:1 (Typ.) (transmission) |
| Best angle | Full view |
| Optical mode | S-IPS, normally black display, transmissive |
| Viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| Responding time | 8 (Typ.)(G to G) ms |
| Number of color | 1.07B, 99% sRGB |
| Backlight type | WLED, 60K hours, with LED driver |
| Stitching | 1.8 mm (active to active seam) |
| Apply to | multi-screen |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | 51 pins LVDS (2 ch, 10-bit), Connector |
| Supply voltage | 12.0V (Typ.) |
| Maximum rating | Working temperature: 0 ~ 50 °C; Storage temperature: -20 ~ 60 °C |
| 49 inch LCD Panel for LG Display LD490DUN-TJA1 LCD Video Wall | |
LG Display LD490DUN-TJA1 Optical Features
| Basic Information : | Luminance (cd/m²) | Viewing Angle (L/R/U/D) | Response Time (ms) |
|---|---|---|---|
| 700 (Typ.) | 89/89/89/89 (Typ.)(CR≥10) | 8 (Typ.)(G to G) | |
| Best View on | Display Mode | Contrast Ratio | |
| Symmetry | S-IPS, Normally Black, Transmissive | 1300 : 1 (Typ.) (Transmissive) | |
| Dispaly Color : | Color Temperature | Display Colors | White Coordinate |
| 9972K | 1.07B (8-bit + Dithering) | X:0.279; Y:0.292 | |
| 1931 Color Gamlt : | NTSC Ratio | sRGB Coverage | Adobe RGB Coverage |
| 72% | 99% | 75% | |
| DCI-P3 Coverage | Rec.2020 Coverage | Remarks | |
| 75% | 54% | sRGB (Rec.709, BT.709), Rec.2020 (BT.2020) | |
| White Variation : | 1.11/1.25 (Typ./Max.)(9 points) | ||
| Performance : | 3D Tech | Sunlight Visibility | Reflectance |
| - | Sunlight Readable | - | |
