LG Display 47 inch LCD video wall LD470DUN-TFB1
Product Details:
Place of Origin: | China |
Brand Name: | LG Display |
Model Number: | LD470DUN-TFB1 |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 pcs |
---|---|
Price: | Negotiable |
Packaging Details: | Original packaging/conventional packaging box |
Delivery Time: | 7 Days |
Payment Terms: | T/T, Western Union |
Supply Ability: | 100000 Unit/Units per Month |
Detail Information |
|||
Model Name: | LD470DUN-TFB1 | Screen Size: | 47.0 Inches |
---|---|---|---|
Pixel Number: | 1920(RGB)×1080[FHD] 46PPI | Active Area(mm): | 1039.68 × 584.82 Mm (H×V) |
Outline(mm): | 1044.9 × 590 × 52.5 Mm (H×V×D) | Bezel Area(mm): | 1040.0 × 585.1 Mm (H×V) |
Luminance: | 500 (Typ.) | Contrast Ratio: | 1400 : 1 (Typ.) [Transmission] |
Product Description
LG Display 47 inch LCD video wall LD470DUN-TFB1
Product details :
LG Display LCD SCREEN LD470DUN-TFB1 | |
manufacturer | LG Display |
Model Name | LD470DUN-TFB1 |
screen size | 47.0 inch |
Screen type | LCM, a-Si TFT-LCD |
Resolution | 1920(RGB)×1080[FHD] 46PPI |
Pixel configuration | RGB vertical bars |
Display size | 1039.68 × 584.82 mm (H×V) |
physical dimension | 1044.9 × 590 × 52.5 mm (H×V×D) |
Visual size | 1040.0 × 585.1 mm (H×V) |
surface treatment | Matte (Haze 10%), Hard coating (3H) |
Brightness | 500cd/m² (Typ.) |
Contrast | 1400:1 (Typ.) (TM) |
Best angle | Full view |
Optical mode | S-IPS, Normally Black, Transmissive |
Viewing angle | 89/89/89/89 (Min.)(CR≥10) |
Responding time | 12 (Typ.)(G to G) ms |
Number of color | 1.06B , 68% NTSC |
Backlight type | WLED , 60K hours, with LED driver |
Patchwork | 5.2 mm (active to active seam) |
Apply to | multi-screen |
Refresh rate | 60Hz |
Touch function | No touch |
signal system | LVDS (2 ch, 10-bit) , terminal, 51 pins |
Supply voltage | 12.0V (Typ.) |
Maximum rating | Storage temperature: -20 ~ 60 °C Operating temperature: 0 ~ 50 °C |
LG Display 47 inch LCD video wall LD470DUN-TFB1 |
LG Display LD470DUN-TFB1 Lightting Details
Lamp Features: | Lamp Shape | - | Lamp Type | WLED | Position | Direct light type |
---|---|---|---|---|---|---|
Exchange | - | Amount | - | Life | 60K(Typ.) (Hours) | |
Interface Features : | Position | - | Physical Type | Connector | ||
Interface Detail : | Brand | Model | Amount | Pin Pitch | Pin Amount | Pin Assignment |
YEONHO | 20022WR-H14B2 | 1 pcs | 2.0 mm | 14 pins | ||
YEONHO | 20022WR-H12B2 | 1 pcs | 2.0 mm | 12 pins | ||
Backlight Driver : | With LED Driver | |||||
Driver Electrical : | Input Current | 3.25/3.75A (Typ./Max.) | Input Voltage | 24.0±1.2V | ||
Consumption | 78.0/90.0W (Typ./Max.) |
