• M230HGE-L20 23 Inch LCD Screen Panel 1920×1080 IPS
  • M230HGE-L20 23 Inch LCD Screen Panel 1920×1080 IPS
M230HGE-L20 23 Inch LCD Screen Panel 1920×1080 IPS

M230HGE-L20 23 Inch LCD Screen Panel 1920×1080 IPS

Product Details:

Place of Origin: China
Brand Name: LG Display
Model Number: M230HGE-L20

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Delivery Time: 7 Days
Payment Terms: T/T, Western Union
Supply Ability: 100000 Unit/Units per Month
Get Best Price Contact Now

Detail Information

Model Name: M230HGE-L20 Screen Size: 23.0 Inch
Pixel Number: 1920(RGB)×1080 [FHD] 95PPI Active Area(mm): 509.184(H)×286.416(V) Mm
Outline(mm): 533.2(H)×312(V) Mm Bezel Area(mm): 513.784(H)×291.016(V) Mm
Luminance: 250 (Typ.) Contrast Ratio: 1000: 1 (Typ.) [Transmission]
High Light:

M230HGE-L20 lcd screen panel


23in lcd screen panel


1080 IPS 23 inch lcd panel

Product Description

M230HGE-L20 23 inch LCD Screen Display Panel



Product details :


Chimei Innolux LCD SCREEN M230HGE-L20
manufacturer Chimei Innolux
Model Name M230HGE-L20
screen size 23.0 inch
Screen type a-Si TFT-LCD , LCM
Resolution 1920(RGB)×1080 [FHD] 95PPI
Pixel configuration RGB Vertical Stripe
Display size 509.184(H)×286.416(V) mm
physical dimension 533.2(H)×312(V) mm
Visual size 513.784(H)×291.016(V) mm
surface treatment Antiglare, Hard coating (3H)
Brightness 250 cd/m² (Typ.)
Contrast 1000:1 (Typ.) (TM)
Best angle 6 o'clock
Optical mode TN, Normally White, Transmissive
Viewing angle 85/85/80/80 (Typ.)(CR≥10)
Responding time 1.5/3.5 (Typ.)(Tr/Td)ms
Number of color 16.7M 72% NTSC
Backlight type WLED , 50K hours , W/O Driver
Panel weight 2.20/2.30Kgs (Typ./Max.)
Apply to Desktop Monitor
Refresh rate 60Hz
Touch function No touch
signal system LVDS (2 ch, 8-bit) , 30 pins Connector
Supply voltage 5.0V (Typ.)
Maximum rating Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
M230HGE-L20 23 inch LCD Screen Display Panel


Why Choose Us :


According to customers' various requests,

we can match all accessories which inclusive of driver board,

touch-screen, LED backlight & LVDS cables. TFT LCD,

LCD panel, LCD display,LCD screen, LCD monitor,

LCD module from 2.2 inch to 88 inch.

Quality promised, 100% original,fast delivery,

also enjoy one year guarantee !


Shipping and Package :


M230HGE-L20 23 Inch LCD Screen Panel 1920×1080 IPS 0

1)All of our product will be testing before shipping . So you can be assured the quality of our products


2) All Panels are packed with new and firm carton, capable of long distance transportation.




4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.




Q: Do you accept sample orders for M230HGE-L20 ?

A: Of course!sample order is welcome !


Q: What happen if the M230HGE-L20 I receive can't work ?

A: The M230HGE-L20 will be tested strictly before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel.


Q: Can you give me a discount if I need a large quantity of M230HGE-L20 ?

A: Of course!If you make a large order, we will give you a discount.


Q: I do not find the LCD I am looking for in the website, what should I do ?

A: You can give us some pictures,we have a lot of LCD out of shelves.




We are one of the professional and experienced suppliers of M230HGE-L20 23 inch LCD Screen Display Panel, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.


*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
