5.6 Inch Industrial LCD Panel Display Chimei Innolux AT056TN53 V.1 Small
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | Chimei Innolux |
| Model Number: | AT056TN53 V.1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Brand: | Chimei Innolux | Model Name: | AT056TN53 V.1 |
|---|---|---|---|
| Screen Size: | 5.6 Inch | Resolution: | 640(RGB)×480, VGA, 143PPI |
| Display Size: | 112.896(W)×84.672(H) Mm | Physical Dimension: | 126.5(W)×100(H)mm |
| Bezel Opening: | 115.70(W)×87.47(H) Mm | Brightness(cd/m²): | 350 Cd/m² (Typ.) |
| Contrast: | 500:1 (Typ.) (TM) | Apply To: | Industrial / Digital Photo Frame / Video Doorbell / Video Phone |
| High Light: | 5.6'' Industrial LCD Panel Display,AT056TN53 Industrial LCD Panel Display,Chimei Innolux 5.6 inch lcd screen |
||
Product Description
CHIMEI INNOLUX AT056TN53 V.1 Small 5.6 inch Industrial LCD Panel Display
Product details :
TFT LCD Panel, LCD/LED backlight
A Grade , 100% New Original
In Stock
| Chimei Innolux LCD SCREEN AT056TN53 V.1 | |
| Panel Brand | Chimei Innolux |
| Panel Model | AT056TN53 V.1 |
| Panel Size | 5.6" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 640(RGB)×480, VGA, 143PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 112.896(W)×84.672(H) mm |
| Bezel Opening | 115.70(W)×87.47(H) mm |
| Outline Size | 126.5(W)×100(H)mm |
| Surface | Antiglare, |
| Brightness | 350 cd/m² (Typ.) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 10/15 (Typ.)(Tr/Td) |
| Display Colors | 262K 50% NTSC |
| Lamp Type | WLED , 20K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 45.0g (Typ.) |
| Signal Interface | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| Input Voltage | 3.3V (Typ.)(VCC) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| CHIMEI INNOLUX AT056TN53 V.1 Small 5.6 inch Industrial LCD Panel Display | |
