6.5 Inch LCD Screen Display TM065JYSP02
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | TIANMA |
| Model Number: | TM065JYSP02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | TIANMA | Model Name: | TM065JYSP02 |
|---|---|---|---|
| Screen Size: | 6.5" | Resolution: | 720(RGB)×1280, WXGA 226PPI |
| Active Area: | 80.598(W)×143.232(H) Mm | Outline Dim.: | 83.168(H)×151.3(V)×0.6(D) Mm |
| View Direction: | Symmetry | Brightness(cd/m²): | 0 Cd/m² |
| Contrast: | 1000:1 (Typ.) (TM) | Used For: | Mobile Phone |
| Highlight: | 4.3 Inch LCD Screen Display Panel,40 Pin LCD Screen Display Panel,272 IPS 4.3 touch screen display |
||
Product Description
6.5 Inch LCD Screen Display TM065JYSP02
Product details :
TFT LCD Panel, LCD/LED backlight
A Grade , 100% New Original
In Stock
| Brand | TIANMA |
| Model P/N | TM065JYSP02 |
| Diagonal Size | 6.5" |
| Panel Type | a-Si TFT-LCD, CELL, Full Cell |
| Resolution | 720(RGB)×1280, WXGA 226PPI |
| Pixel Format | RGB Vertical Stripe |
| Active Area | 80.598(W)×143.232(H) mm |
| Bezel Opening | - |
| Outline Dim. | 83.168(H)×151.3(V)×0.6(D) mm |
| Treatment | - |
| Luminance | 0 cd/m² |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 35 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating Mode | FFS, Normally Black |
| Plate Thickness | 0.30+0.30 mm |
| Transmittance | 5.9% (Typ.) |
| Support Color | 16.7M 72%NTSC |
| Light Source | No B/L |
| Weight | - |
| Designed For | Mobile Phone |
| Frame Rate | - |
| Touch Panel | Without |
| D-IC Detail | COG Suggest HX8394A, HX8394A, OTM1283A, NT35521 |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
