21.3 inch TX54D14VC0CAA TFT LCD Screen Display Panel
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | JDI |
| Model Number: | TX54D14VC0CAA |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | JDI | Model Name: | TX54D14VC0CAA |
|---|---|---|---|
| Screen Size: | 21.3 Inches | Resolution: | 1600(RGB)×1200 UXGA 94PPI |
| Display Size: | 432 × 324 (H×V) | Physical Dimension: | 460.6 × 362 × 28 (H×V×D) |
| Brightness(cd/m²): | 820 Cd/m² (Typ.) | Contrast: | 1100 : 1 (Typ.) (TM) |
| Viewing Angle: | 85/85/85/85 (Typ.)(CR≥10) | Used For: | Medical Imaging |
Product Description
21.3 inch TX54D14VC0CAA TFT LCD Screen Display Panel
Product details :
TFT LCD Panel, LCD/LED backlight
A Grade , 100% New Original
In Stock
| JDI LCD SCREEN TX54D14VC0CAA | |
| Manufacturer | JDI |
| Model Name | TX54D14VC0CAA |
| Screen Size | 21.3 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1600(RGB)×1200 (UXGA) 94PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 432 × 324 (H×V) |
| Outline(mm) | 460.6 × 362 × 28 (H×V×D) |
| Treatment | Antiglare |
| Luminance | 820 cd/m² (Typ.) |
| Contrast Ratio | 1100 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Response | 12/10 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | IPS-Pro, Normally Black, Transmissive |
| Color Depth | 16.7M 99% sRGB |
| Backlight | 3 strings WLED , With LED Driver |
| Mass | 3.00/3.40Kgs (Typ./Max.) |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| 21.3 inch TX54D14VC0CAA TFT LCD Screen Display Panel | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ :
Q: Can you give me a discount if I need a large quantity of TX54D14VC0CAA ?
A: Of course!If you make a large order, we will give you a discount.
Q: How long will I receive my goods TX54D14VC0CAA ?
A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.
Q: Can You declare my order of TX54D14VC0CAA to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can I pay my order of TX54D14VC0CAA via credit card ?
A: Yes!you can use your credit card through your Paypal account.
We are one of the professional and experienced suppliers of 21.3 inch TX54D14VC0CAA TFT LCD Screen Display Panel, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
