P460HVN01.3 46 Inch LCD Wall Display AUO LCD Panel
Product Details:
| Place of Origin: | China |
| Brand Name: | AUO |
| Model Number: | P460HVN01.3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Model Name: | P460HVN01.3 | Screen Size: | 46.0 Inch |
|---|---|---|---|
| Pixel Number: | 1920(RGB)×1080, FHD, 47PPI | Active Area(mm): | 1018.08(W)×572.67(H) Mm |
| Outline(mm): | 1023.68(W)×578.27(H) ×55.2(D) Mm | Bezel Area(mm): | 1018.68(W)×573.27(H) Mm |
| Luminance: | 500 (Typ.) | Contrast Ratio: | 4000: 1 (Typ.) [Transmission] |
| High Light: | AUO lcd wall display,46'' lcd wall display,P460HVN01.3 auo lcd panel |
||
Product Description
AUO lcd panel P460HVN01.3 46.0 inch LCD video wall
Product details :
| AUO LCD SCREEN P460HVN01.3 | |
| Panel Brand | AUO |
| Panel Model | P460HVN01.3 |
| Panel Size | 46" |
| Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1920(RGB)×1080, FHD, 47PPI |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 1018.08(W)×572.67(H) mm |
| Bezel Opening | 1018.68(W)×573.27(H) mm |
| Outline Size | 1023.68(W)×578.27(H) ×55.2(D) mm |
| Surface | Antiglare (Haze 44%) |
| Brightness | 500 cd/m² (Typ.) |
| Contrast Ratio | 4000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | AMVA3, Normally Black, Transmissive |
| Response Time | 6.5 (Typ.)(G to G) |
| Display Colors | 1.07B 72% NTSC |
| Lamp Type | WLED , 50K hours , With LED Driver |
| Apply to | multi-screen |
| Frequency | 60Hz |
| Touch Screen | Without |
| Videowall Seam | 5.6 mm (active to active seam) |
| Signal Interface | LVDS (2 ch, 8/10-bit) , 51 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| AUO lcd panel P460HVN01.3 46.0 inch LCD video wall | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ:
Q: Do you accept sample orders of P460HVN01.3 ?
A: Of course!sample order is welcome !
Q: Can you give me a discount if I need a large quantity of P460HVN01.3?
A: Of course!If you make a large order, we will give you a discount.
Q: How to make payment of P460HVN01.3 ?
A: We accept T/T , Paypal , western union .
Q: Can You declare my order of P460HVN01.3 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
