LM238WF5-SSC1 LCD Screen Display Panel 23.8 Inch TFT
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | LG Display |
| Model Number: | LM238WF5-SSC1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | LG Display | Model Name: | LM238WF5-SSC1 |
|---|---|---|---|
| Screen Size: | 23.8 Inch | Resolution: | 1920(RGB)×1080 FHD 92PPI |
| Display Size: | 527.04(H)×296.46(V) Mm | Physical Dimension: | 541.31(H)×316.95(V) ×11.35(T) Mm |
| Brightness(cd/m²): | 250cd/m² (Typ.) | Contrast: | 1000:1 (Typ.) (TM) |
| Touchscreen: | On-Cell Touch | Apply To: | Computer Monitor |
| High Light: | LM238WF5-SSC1 lcd screen display panel,23.8'' lcd screen display panel,TFT lcd display screen |
||
Product Description
LM238WF5-SSC1 LCD Touch Panel Display 23.8 inch IPS Display Panel
Product details :
TFT LCD Panel, LCD/LED backlight
A Grade , 100% New Original
In Stock
| LG Display LCD SCREEN LM238WF5-SSC1 | |
| Manufacturer | LG Display |
| Model Name | LM238WF5-SSC1 |
| Screen Size | 23.8 inch |
| Types of | a-Si TFT-LCD, LCM |
| Resolution | 1920(RGB)×1080 FHD 92PPI |
| Pixel arrangement | RGB vertical bar |
| Display area | 527.04(H)×296.46(V) mm |
| physical dimension | 541.31(H)×316.95(V) ×11.35(T) mm |
| Surface treatment | Mirror (Haze 0%), Hard coating (3H) |
| Display brightness | 250 cd/m2 (Typ.) |
| Contrast | 1000:1 (Typ.) (transmission) |
| Recommended perspective | Full view |
| Response time | 14 (Typ.)(G to G) ms |
| Viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display mode | IPS, normally black display, transmissive |
| Support color | 16.7M, 72% NTSC |
| type of light source | WLED, 30K hours, no driver |
| weight | 2.25/2.36Kgs (Typ./Max.) |
| Frame rate | 60Hz |
| Interface Type | 30 pins LVDS (2 ch, 8-bit), connector |
| Voltage supply | 5.0V (Typ.) |
| Application Environment | Working temperature: 0 ~ 50 °C; Storage temperature: -20 ~ 60 °C |
| LM238WF5-SSC1 LCD Touch Panel Display 23.8 inch IPS Display Panel | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ :
Q: Can You declare my order of LM238WF5-SSC1 to a lower price in commercial invoice for customs ?
A: Yes , we can . pls inform us before shipping .
Q: Can you give me a discount if I need a large quantity of LM238WF5-SSC1 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How to make payment of LM238WF5-SSC1 ?
A: We accept T/T , Paypal , western union .
Q: Do you accept sample orders of LM238WF5-SSC1 ?
A: Of course!sample order is welcome !
We are one of the professional and experienced suppliers of LM238WF5-SSC1 LCD Touch Panel Display 23.8 inch IPS Display Panel, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
