IPS 1080p 18.5 inch AUO display G185HAN01.0 TFT LCD Panel for Industrial LCD Panel Display
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | AUO |
| Model Number: | G185HAN01.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | AUO | Model Name: | G185HAN01.0 |
|---|---|---|---|
| Screen Size: | 18.5 Inch | Resolution: | 1920(RGB)×1080 (FHD) 119PPI |
| Screen Type: | A-Si TFT-LCD, LCD Module | Display Size: | 408.96 × 230.04 (H×V) |
| Physical Dimension: | 430.4 × 254.6 × 12.5 (H×V×D) | Visual Size: | 410.96 × 232.04 (H×V) |
| Luminanceration: | 350cd/m² (Typ.) | Contrast Ratio: | 1000:1 (Typ.) (transmission) |
| Responding Time: | 10/10 (Typ.)(Tr/Td) Ms | Used For: | Industrial / Medical Imaging |
Product Description
IPS 1080p 18.5 inch AUO display G185HAN01.0 TFT LCD Panel for Industrial LCD Panel Display
Product details :
TFT LCD Panel, LCD/LED backlight
A Grade , 100% New Original
In Stock
| AUO LCD SCREEN G185HAN01.0 | |
| Manufacturer | AUO |
| Model Name | G185HAN01.0 |
| Screen Size | 18.5" |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 119PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 408.96 × 230.04 (H×V) |
| Outline(mm) | 430.4 × 254.6 × 12.5 (H×V×D) |
| Bezel Area(mm) | 410.96 × 232.04 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 10/10 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AHVA, Normally Black, Transmissive |
| Color Depth | 16.7M 99% sRGB |
| Backlight | 9S7P WLED , 50K hours , With LED Driver |
| Mass | 1.20Kgs (Typ.) |
| Used for | Industrial / Medical Imaging |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 70 °C |
| IPS 1080p 18.5 inch AUO display G185HAN01.0 TFT LCD Panel for Industrial LCD Panel Display | |
