G070VW01 V0 7 Inch Industrial LCD Panel Display TFT 800x480 IPS
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | AUO |
| Model Number: | G070VW01 V0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | AUO | Model Name: | G070VW01 V0 |
|---|---|---|---|
| Screen Size: | 7.0 Inch | Resolution: | 800(RGB)×480 WVGA 133PPI |
| Screen Type: | A-Si TFT-LCD, LCD Module | Display Size: | 152.4(Horizontal)×91.44(Vertical) Mm |
| Physical Dimension: | 170 (horizontal) × 111 (vertical) × 8 (thick) Mm | Visual Size: | 155.2(Horizontal)×94.24(Vertical) Mm |
| Luminanceration: | 400cd/m² (Typ.) | Contrast Ratio: | 750:1 (Typ.) (transmission) |
| Responding Time: | 20/10 (Typ.)(Tr/Td) Ms | Used For: | Industrial |
| High Light: | G070VW01 Industrial LCD Panel Display,7'' Industrial LCD Panel Display,480 IPS 7 inch lcd display screen |
||
Product Description
a-Si TFT-LCD Display G070VW01 V0 7 inch 800x480 Lcd Screen use for industrial LCD Panel Display
Product details :
TFT LCD Panel, LCD/LED backlight
A Grade , 100% New Original
In Stock
| AUO LCD SCREEN G070VW01 V0 | |
| manufacturer | AUO |
| Model Name | G070VW01 V0 |
| screen size | 7.0 inch |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 800(RGB)×480 WVGA 133PPI |
| Pixel configuration | RGB vertical bar |
| Display size | 152.4(Horizontal)×91.44(Vertical) mm |
| physical dimension | 170 (horizontal) × 111 (vertical) × 8 (thick) mm |
| Visual size | 155.2(Horizontal)×94.24(Vertical) mm |
| surface treatment | Matte, Hard coating (3H) |
| Brightness | 400cd/m² (Typ.) |
| Contrast | 750:1 (Typ.) (transmission) |
| Optical mode | TN, normally white display, transmissive |
| Viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| Responding time | 20/10 (Typ.)(Tr/Td) ms |
| Number of color | 262K/16.2M, 60% NTSC |
| Backlight type | WLED, 50K hours, with LED driver |
| Panel weight | 165/175g (Typ./Max.) |
| Apply to | industry |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | 20 pins LVDS (1 ch, 6/8-bit), connector |
| Supply voltage | 3.3V (Typ.) |
| Maximum rating | Working temperature: -30 ~ 85 °C; Storage temperature: -30 ~ 85 °C |
| a-Si TFT-LCD Display G070VW01 V0 7 inch 800x480 Lcd Screen use for industrial LCD Panel Display | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ :
Q: Do you accept sample orders of G070VW01 V0 ?
A: Of course! Sample order is welcome.
Q: Can I pay my order of G070VW01 V0 vai credit card ?
A: Yes! You can use your credit card through your Paypal account.
Q: How long is the warranty ?
A: We offer 90 days warranty.
Q: If I place order now, when will you ship the goods of G070VW01 V0 ?
A: The order will be shipped within 2-3 working days after received your payment.
We are one of the professional and experienced suppliers of a-Si TFT-LCD Display G070VW01 V0 7 inch 800x480 Lcd Screen use for industrial LCD Panel Display, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
