AUO G104SN03 V5 Industrial LCD Panel Display 10.4 Inch
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | AUO |
| Model Number: | G104SN03 V5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | AUO | Model Name: | G104SN03 V5 |
|---|---|---|---|
| Screen Size: | 10.4 Inch | Resolution: | 800(RGB)×600, SVGA, 96PPI |
| Screen Type: | A-Si TFT-LCD, LCD Module | Display Size: | 211.2(W)×158.4(H) Mm |
| Physical Dimension: | 236(W)×176.9(H) ×6(D) Mm | Visual Size: | 214.8(W)×162.0(H) Mm |
| Luminanceration: | 230 Cd/m² (Typ.) | Contrast Ratio: | 800 : 1 (Typ.) (TM) |
| Responding Time: | 10/5 (Typ.)(Tr/Td) Ms | Used For: | Industrial |
| High Light: | G104SN03 Industrial LCD Panel Display,AUO Industrial LCD Panel Display,10.4'' auo screen |
||
Product Description
AUO G104SN03 V5 Industrial LCD Panel Display 10.4 Inch LCD Module
Product details :
TFT LCD Panel, LCD/LED backlight
A Grade , 100% New Original
In Stock
| AUO LCD SCREEN G104SN03 V5 | |
| manufacturer | AUO |
| Model Name | G104SN03 V5 |
| screen size | 10.4 inch |
| Screen type | a-Si TFT-LCD, LCD module |
| Resolution | 800(RGB)×600, SVGA, 96PPI |
| Pixel configuration | RGB vertical bar |
| Display size | 211.2(W)×158.4(H) mm |
| physical dimension | 236(W)×176.9(H) ×6(D) mm |
| Visual size | 214.8(W)×162.0(H) mm |
| surface treatment | Matte, Hard coating (3H) |
| Brightness | 230cd/m² (Typ.) |
| Contrast | 500:1 (Typ.) (TM) |
| Optical mode | TN, normally white display, transmissive |
| Viewing angle | 80/80/60/70 (Typ.)(CR=10) |
| Responding time | 10/5 (Typ.)(Tr/Td) ms |
| Number of color | 262K/16.2M, 50% NTSC |
| Backlight type | 3 strings WLED, 25K hours, with LED driver |
| Panel weight | 280g (Typ.) |
| Apply to | industry |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | 20 pins LVDS (1 ch, 6/8-bit), connector |
| Supply voltage | 3.3V (Typ.) |
| Maximum rating | Working temperature: -20 ~ 70 °C; Storage temperature: -20 ~ 70 °C |
| AUO G104SN03 V5 Industrial LCD Panel Display 10.4 Inch LCD Module | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ :
Q: Can you give me a discount if I need a large quantity of G104SN03 V5 ?
A: Of course!If you make a large order, we will give you a discount.
Q: If I place order now,when will you ship the goods of G104SN03 V5 ?
A: The order will be shipped within 2-3 working days after received your payment.
Q: How can I trace my order of G104SN03 V5 ?
A: we will give you tracking number then you can trace your order from website.
Q: Do you accept sample orders of G104SN03 V5 ?
A: Of course!sample order is welcome !
We are one of the professional and experienced suppliers of AUO G104SN03 V5 Industrial LCD Panel Display 10.4 Inch LCD Module, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
