WF39BSQASDNN0 Winstar Stretched Bar LCD 3.9 Inch With High Brightness Wide Temperature 480x128
Product Details:
| Place of Origin: | China |
| Brand Name: | Winstar |
| Model Number: | WF39BSQASDNN0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | Winstar | Model Name: | WF39BSQASDNN0 |
|---|---|---|---|
| Screen Size: | 3.9" (1/2 Cut Of 4.3") | Resolution: | 480×128(RGB), 128PPI |
| Active Area: | 95.04(W)×25.34(H) Mm | Outline: | 105.5(W)×37(H) ×3.25(D) Mm |
| Bezel Opening: | 97.04(W)×27.34(H) Mm | Brightness: | 1000 Cd/m² (Typ.) |
| Contrast Ratio: | 500:1 (Typ.) (TM) | Apply To: | Industrial / Stretched Bar LCD /Automotive Display |
| High Light: | WF39BSQASDNN0 Stretched Bar LCD,WF39BSQASDNN0 480 Stretched Bar LCD,WF39BSQASDNN0 3.9'' tft lcd screen module |
||
Product Description
Winstar Stretched Bar LCD Display 3.9 inch WF39BSQASDNN0 with High Brightness Wide Temperature 480x128
Product details :
TFT LCD Panel, LCD/LED backlight
A Grade , 100% New Original
In Stock
| Winstar LCD SCREEN WF39BSQASDNN0 | |
| manufacturer | Winstar |
| Model Name | WF39BSQASDNN0 |
| screen size | 3.9 inch (1/2 cut of 4.3") |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 480×128(RGB), 128PPI |
| Pixel configuration | RGB Horizontal Stripe |
| Display size | 95.04(W)×25.34(H) mm |
| physical dimension | 105.5(W)×37(H) ×3.25(D) mm |
| Visual size | 97.04(W)×27.34(H) mm |
| surface treatment | Antiglare |
| Brightness | 1000 cd/m² (Typ.) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Optical mode | TN, Normally White, Transmissive |
| Viewing angle | 65/65/65/65 (Typ.)(CR≥10) |
| Number of color | 16.7M |
| Backlight type | 7S2P WLED , 50K hours , Without Driver |
| Apply to | Industrial / Stretched Bar LCD / Automotive Display |
| Touch function | Without |
| signal system | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| Supply voltage | 3.3V (Typ.) |
| Maximum rating | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -40 ~ 90 °C |
| Winstar Stretched Bar LCD Display 3.9 inch with High Brightness Wide Temperature 480x128 | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ :
Q: Can you give me a discount if I need a large quantity of WF39BSQASDNN0 ?
A: Of course!If you make a large order, we will give you a discount.
Q: Can I pay my order of WF39BSQASDNN0 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: How can I trace my order of WF39BSQASDNN0 ?
A: we will give you tracking number then you can trace your order from website.
Q: How long is the warranty ?
A: We offer 90days warranty .
We are one of the professional and experienced suppliers of Winstar Stretched Bar LCD Display 3.9 inch WF39BSQASDNN0 with High Brightness Wide Temperature 480x128, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
