7.84 Inch TM078XYHP10 Stretched Bar LCD 1280×400 IPS

7.84 Inch TM078XYHP10 Stretched Bar LCD 1280×400 IPS

Product Details:

Place of Origin: China
Brand Name: TIANMA
Model Number: TM078XYHP10

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Delivery Time: 7 Days
Payment Terms: T/T, Western Union
Supply Ability: 100000 Unit/Units per Month
Get Best Price Contact Now

Detail Information

Manufacturer: TIANMA Model Name: TM078XYHP10
Screen Size: 7.8 Inch (Native Bar) Resolution: 1280×400(RGB) 171PPI
Active Area: 190.08(H)×59.4(V) Mm Outline Dim.: 199.88(H)×64.2(V) ×1(D) Mm
Luminance: 0 Cd/m² Response Time: 25 (Typ.)(Tr+Td)
Contrast: 1200:1 (Typ.) (TM) Apply To: Stretched Bar LCD / Automotive Display
High Light:

TM078XYHP10 Stretched Bar LCD

,

TM078XYHP10 7.84'' Stretched Bar LCD

,

TM078XYHP10 400 IPS bar lcd screen

Product Description

7.84 Inch LCD Display TM078XYHP10 Stretched Bar LCD



Product details :



TFT LCD Panel, LCD/LED backlight



A Grade , 100% New Original



In Stock

TIANMA LCD SCREEN TM078XYHP10
manufacturer TIANMA
Model Name TM078XYHP10
screen size 7.8 inch (Native bar)
Screen type a-Si TFT-LCD, CELL
Resolution 1280×400(RGB) 171PPI
Pixel configuration RGB Horizontal Stripe
Display size 190.08(H)×59.4(V) mm
physical dimension 199.88(H)×64.2(V) ×1(D) mm
Brightness 0cd/m² (Typ.)
Contrast 900:1 (Typ.) (TM)
Best angle Full view
Optical mode SFT, Normally Black, Transmissive
Viewing angle 80/80/80/80 (Typ.)(CR≥10)
Responding time 25 (Typ.)(Tr+Td)ms
Number of color 16.7M 70% NTSC
Backlight type No B/L
Plate Thickness 0.50+0.50 mm
Transmittance 4.6% (Typ.)
Panel weight TBD
Apply to Stretched Bar LCD / Automotive Display
Touch function No touch
D-IC Detail COG Suggest EK79030
Maximum rating Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
7.84 Inch LCD Display TM078XYHP10 Stretched Bar LCD



Why Choose Us :



According to customers' various requests,


we can match all accessories which inclusive of driver board,


touch-screen, LED backlight & LVDS cables. TFT LCD,


LCD panel, LCD display,LCD screen, LCD monitor,


LCD module from 2.2 inch to 88 inch.


Quality promised, 100% original,fast delivery,


also enjoy one year guarantee !



Shipping and Package :

7.84 Inch TM078XYHP10 Stretched Bar LCD 1280×400 IPS 0



1)All of our product will be testing before shipping . So you can be assured the quality of our products



2) All Panels are packed with new and firm carton, capable of long distance transportation.



3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT



4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.



FAQ :



Q: Can I pay my order of TM078XYHP10 via credit card ?

A: Yes!you can use your credit card through your Paypal account.



Q: How long is the warranty ?

A: We offer 90days warranty .



Q: If I place order now,when will you ship the goods of TM078XYHP10 ?

A: The order will be shipped within 2-3 working days after received your payment.



Q: How can I trace my order of TM078XYHP10 ?

A: we will give you tracking number then you can trace your order from website.





We are one of the professional and experienced suppliers of 7.84 Inch LCD Display TM078XYHP10 Stretched Bar LCD, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.



*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
