• 28.6 Inch LCD Screen Panel S290AJ1-LE1 Innolux 1920×540 IPS
  • 28.6 Inch LCD Screen Panel S290AJ1-LE1 Innolux 1920×540 IPS
28.6 Inch LCD Screen Panel S290AJ1-LE1 Innolux 1920×540 IPS

28.6 Inch LCD Screen Panel S290AJ1-LE1 Innolux 1920×540 IPS

Product Details:

Place of Origin: China
Brand Name: Innolux
Model Number: S290AJ1-LE1

Payment & Shipping Terms:

Minimum Order Quantity: 1 pcs
Price: Negotiable
Packaging Details: Original packaging/conventional packaging box
Delivery Time: 7 Days
Payment Terms: T/T, Western Union
Supply Ability: 100000 Unit/Units per Month
Get Best Price Contact Now

Detail Information

Manufacturer: Innolux Model Name: S290AJ1-LE1
Screen Size: 28.6 Inch (1/2 Cut Of 32.0") Resolution: 1920(RGB)×540 69PPI
Active Area: 698.4(H)×196.425(V) Mm Outline Dim.: 731.46(H)×229.49(V) ×30.2(D) Mm
Bezel Area: 702.4(H)×200.43(V) Mm Luminance: 1000 Cd/m² (Typ.)
Contrast: 4500:1 (Typ.) (TM) Apply To: Digital Signage / Outdoor High Brightness / Stretched Bar LCD
High Light:

28.6'' lcd screen panel


S290AJ1-LE1 lcd screen panel


540 IPS lcd tft display module

Product Description

Innolux 28.6 inch Stretched Bar LCD S290AJ1-LE1


Product details :


TFT LCD Panel, LCD/LED backlight


A Grade , 100% New Original


In Stock

Innolux LCD SCREEN S290AJ1-LE1
manufacturer Innolux
Model Name S290AJ1-LE1
screen size 28.6 inch (1/2 cut of 32.0")
Screen type a-Si TFT-LCD , LCM
Resolution 1920(RGB)×540 69PPI
Pixel configuration RGB Vertical Stripe
Display size 698.4(H)×196.425(V) mm
physical dimension 731.46(H)×229.49(V) ×30.2(D) mm
Visual size 702.4(H)×200.43(V) mm
surface treatment Antiglare (Haze 3.4%)
Brightness 1000cd/m² (Typ.)
Contrast 4500:1 (Typ.) (TM)
Best angle Full view
Optical mode Super MVA, Normally Black, Transmissive
Viewing angle 89/89/89/89 (Typ.)(CR≥10)
Responding time 8.5 (Typ.)(G to G)ms
Number of color 16.7M 72% NTSC
Backlight type WLED , 50K hours , With LED Driver
Panel weight 2.40±0.12g
Apply to Digital Signage / Outdoor High Brightness / Stretched Bar LCD
Refresh rate 60Hz
Touch function No touch
signal system LVDS (2 ch, 8-bit) , 51 pins Connector
Supply voltage 12.0V (Typ.)
Maximum rating Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
Innolux 29 inch Stretched Bar LCD S290AJ1-LE1


Why Choose Us :


According to customers' various requests,

we can match all accessories which inclusive of driver board,

touch-screen, LED backlight & LVDS cables. TFT LCD,

LCD panel, LCD display,LCD screen, LCD monitor,

LCD module from 2.2 inch to 88 inch.

Quality promised, 100% original,fast delivery,

also enjoy one year guarantee !


Shipping and Package :

28.6 Inch LCD Screen Panel S290AJ1-LE1 Innolux 1920×540 IPS 0


1)All of our product will be testing before shipping . So you can be assured the quality of our products


2) All Panels are packed with new and firm carton, capable of long distance transportation.




4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.




Q: Can you give me a discount if I need a large quantity of S290AJ1-LE1 ?

A: Of course!If you make a large order, we will give you a discount.


Q: Can You declare my order of S290AJ1-LE1 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .


Q: How to make payment of S290AJ1-LE1 ?

A: We accept T/T , Paypal , western union .


Q: How long is the warranty ?

A: We offer 90 days warranty .



We are one of the professional and experienced suppliers of Innolux 29 inch Stretched Bar LCD S290AJ1-LE1, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.


*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !

Want to Know more details about this product
I am interested in 28.6 Inch LCD Screen Panel S290AJ1-LE1 Innolux 1920×540 IPS could you send me more details such as type, size, quantity, material, etc.
Waiting for your reply.
