New Lcd DISPLAY S072WX02 Stretched Bar LCD
Product Details:
| Place of Origin: | China |
| Brand Name: | CDTECH |
| Model Number: | S072WX02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | CDTECH | Model Name: | S072WX02 |
|---|---|---|---|
| Screen Size: | 7.2 Inch (1/2 Cut Of 8.0") | Resolution: | 1280(RGB)×370 187PPI |
| Active Area: | 173.76(H)×50.23(V) Mm | Outline Dim.: | 186.18(H)×67.35(V) Mm |
| Bezel Area: | 177.16(H)×55.53(V) Mm | Luminance: | 1000 Cd/m² (Typ.) |
| Contrast: | 400:1 (Typ.) (TM) | Apply To: | Automotive Display / Industrial / Outdoor High Brightness / Stretched Bar LCD |
Product Description
new lcd DISPLAY S072WX02 Stretched Bar LCD
Product details :
TFT LCD Panel, LCD/LED backlight
A Grade , 100% New Original
In Stock
| CDTECH LCD SCREEN S072WX02 | |
| manufacturer | CDTECH |
| Model Name | S072WX02 |
| screen size | 7.2 inch (1/2 cut of 8.0") |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 1280(RGB)×370 187PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 173.76(H)×50.23(V) mm |
| physical dimension | 186.18(H)×67.35(V) mm |
| Visual size | 177.16(H)×55.53(V) mm |
| Brightness | 1000cd/m² (Typ.) |
| Contrast | 400:1 (Typ.) (TM) |
| Best angle | 12 o'clock |
| Optical mode | TN, Normally White, Transmissive |
| Viewing angle | 65/65/55/65 (Typ.)(CR≥10) |
| Responding time | 25/25 (Typ.)(Tr/Td)ms |
| Number of color | 262K 51% NTSC |
| Backlight type | WLED [5S6P] , 30K hours , W/O Driver |
| Panel weight | TBD |
| Apply to | Automotive Display / Industrial / Outdoor High Brightness / Stretched Bar LCD |
| Refresh rate | 60Hz |
| Touch function | No touch |
| signal system | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| Supply voltage | 3.3/12.63/22/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| Maximum rating | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| new lcd DISPLAY S072WX02 Stretched Bar LCD | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ :
Q: Can you tested the S072WX02 before shipping ?
A: Of course , our lcd panel B101EAN01.8 was Strictly tested before shipping.
Q: How to order CDTECH S072WX02 ?
A: We accept T/T , Paypal , western union .
Q: How long the warranty of the lcd S072WX02 ?
A: 90 days .
Q: What happen if the lcd panel S072WX02 I received can't work ?
A: CDTECH S072WX02 was tesed before shipping.If happen that , pls check all the connect cable again,If still has problems ,we accept exchange or return panel .
We are one of the professional and experienced suppliers of new lcd DISPLAY S072WX02 Stretched Bar LCD, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
