3.9 Inch S039WQ01 Bar LCD Panel 480×128 IPS 128PPI
Product Details:
| Place of Origin: | China |
| Brand Name: | CDTECH |
| Model Number: | S039WQ01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Original packaging/conventional packaging box |
| Delivery Time: | 7 Days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 100000 Unit/Units per Month |
|
Detail Information |
|||
| Manufacturer: | CDTECH | Model Name: | S039WQ01 |
|---|---|---|---|
| Screen Size: | 3.9 Inch (1/2 Cut Of 4.3") | Resolution: | 480(RGB)×128 128PPI |
| Active Area: | 95.04(H)×25.34(V) Mm | Outline Dim.: | 105.5(H)×40.64(V) ×3.15(D) Mm |
| Bezel Area: | 98.04(H)×28.34(V) Mm | Luminance: | 500 Cd/m² (Typ.) |
| Contrast: | 500:1 (Typ.) (TM) | Apply To: | Industrial / Stretched Bar LCD / Automotive Display |
| High Light: | 3.9'' bar lcd panel,128 IPS bar lcd panel,480 IPS display panel lcd |
||
Product Description
new lcd DISPLAY S039WQ01
Product details :
TFT LCD Panel, LCD/LED backlight
A Grade , 100% New Original
In Stock
| CDTECH LCD SCREEN S039WQ01 | |
| manufacturer | CDTECH |
| Model Name | S039WQ01 |
| screen size | 3.9 inch (1/2 cut of 4.3") |
| Screen type | a-Si TFT-LCD , LCM |
| Resolution | 480(RGB)×128 128PPI |
| Pixel configuration | RGB Vertical Stripe |
| Display size | 95.04(H)×25.34(V) mm |
| physical dimension | 105.5(H)×40.64(V) ×3.15(D) mm |
| Visual size | 98.04(H)×28.34(V) mm |
| Brightness | 500cd/m² (Typ.) |
| Contrast | 500:1 (Typ.) (TM) |
| Best angle | 12 o'clock |
| Optical mode | TN, Normally White, Transmissive |
| Viewing angle | 65/65/55/65 (Typ.)(CR≥10 |
| Responding time | 10/15 (Typ.)(Tr/Td)ms |
| Number of color | 16.7M 50% NTSC |
| Backlight type | WLED [5S2P] , 30K hours , W/O Driver |
| Panel weight | TBD |
| Apply to | Industrial / Stretched Bar LCD / Automotive Display |
| Touch function | No touch |
| signal system | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| Supply voltage | 3.3/3.3V (Typ.)(VDD/PVDD) |
| Maximum rating | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| new lcd DISPLAY S039WQ01 | |
Why Choose Us :
According to customers' various requests,
we can match all accessories which inclusive of driver board,
touch-screen, LED backlight & LVDS cables. TFT LCD,
LCD panel, LCD display,LCD screen, LCD monitor,
LCD module from 2.2 inch to 88 inch.
Quality promised, 100% original,fast delivery,
also enjoy one year guarantee !
Shipping and Package :
1)All of our product will be testing before shipping . So you can be assured the quality of our products
2) All Panels are packed with new and firm carton, capable of long distance transportation.
3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT
4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.
FAQ :
Q: Can I pay my order of S039WQ01 via credit card ?
A: Yes!you can use your credit card through your Paypal account.
Q: Can you give me a discount if I need a large quantity of S039WQ01 ?
A: Of course!If you make a large order, we will give you a discount.
Q: How can I trace my order of S039WQ01 ?
A: we will give you tracking number then you can trace your order from website.
Q: Do you accept sample orders of S039WQ01 ?
A: Of course!sample order is welcome !
We are one of the professional and experienced suppliers of new lcd DISPLAY S039WQ01, offering you the quotation and the price list consultation. Welcome to wholesale the high-end, quality and low price products in stock with us. Good after-sale service and fast delivery are available.
*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
